GENE-EHL7
SubCompact Board with Intel Atom® x6000E Series, and Intel® Pentium® and Celeron® N and J Series Processors
As low as
US$224.00
Availability:
In stock
Inventory: please select an item
SKU
GENE-EHL7
With its energy-efficient processing capabilities, versatile array of interfaces, and adaptable expansion options, the GENE-EHL7 redefines efficiency and cost-effectiveness, serving as an indispensable cornerstone for a wide spectrum of vertical market applications. Despite its compact form factor, the GENE-EHL7 boasts a diminutive footprint measuring only 146mm x 101.7mm and weighs less than 1 lb., rendering it an ideal candidate for unobtrusive deployment in the most space-constrained application scenarios. Despite this, it offers an extensive set of value-enhancing features, including multi-display support, seamless peripheral device integration, and wireless communication capabilities, granting a net positive when it comes to its ratio of cost to value.
GENE-EHL7-A10-0001
| SYSTEM | |
| Form Factor | 3.5'' SubCompact Board |
| CPU | Intel® Celeron® N6210 (2C/2T, 1.20GHz, 6.5W) |
| Chipset | Integrated with Intel ® SoC |
| Memory Type | Single-Channel DDR4 3200MHz SODIMM x 1, Max. 32GB, Non-ECC *IBECC supported by selected CPU SKU |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Level |
| Security | TPM 2.0 |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION (L X W) | 5.75" x 4" (146mm x 101.7mm), 0.83 lbs (0.38 kg) |
| OS SUPPORT | Windows 10 (64bit) Linux Ubuntu 20.04.5 / 5.15.0-46-generic |
| POWER | |
| Power Requirement | +12V |
| Power Supply Type | AT/ATX |
| Power Connector | Phoenix 2-pin Connector |
| Power Consumption | Intel Atom® x6413E, DDR4 32GB, 2.17A @+12V (Typical) Intel Atom® x6413E, DDR4 32GB, 2.72A @+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | Dual-Channel 18/24-bit LVDS x 1, up to 1920 x 1080 eDP 1.3 x 1, up to 1920 x 1200 (Optional) |
| Display Interface | HDMI 1.4 x 1, up to 3840 x 2160 @ 30Hz DP 1.4 x 1, up to 3840 x 2160 @ 120Hz |
| MULTIPLE DISPLAY | Up to 3 Simultaneous Displays |
| AUDIO | |
| CODEC | REALTEK ALC897 |
| AUDIO INTERFACE | Line-in/Line-out/MIC |
| SPEAKER | — |
| EXTERNAL I/O | |
| ETHERNET | Realtek RTL8111H 1GbE, RJ-45 x 2 |
| USB | USB3.2 Gen 2 x 2 |
| VIDEO | HDMI 1.4 x 1, DP1.4 x 1 |
| INTERNAL I/O | |
| USB | USB2.0 x 4 |
| SERIAL PORT | COM1 (RS232/422/485, supports 5V/12V/RI) COM2 (RS232) |
| VIDEO | LVDS / eDP x 1 (Default: LVDS) Inverter x 1 (12V/2A) |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio Header x 1 |
| DIO/GPIO | GPIO 8-bits |
| SMBUS/I2C | SMBus / I2C x 1 (Default: SMBus) |
| TOUCH | 4/5/8-wire Touch Controller x 1 |
| FAN | 4pins Smart Fan x 1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| Mini PCI-E/mSATA | Full-size mPCIe x 1 |
| M.2 | M.2 2230 E-Key x 1 (PCIe 3.0 [x1], USB2.0) M.2 2280 M-Key x 1 (PCIe 3.0 [x2] / SATA), SATA select by BOM |
| ENVIRONMENT & CERTIFICATION | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 484,355 |
| Certification | CE/FCC Class A |
GENE-EHL7-A10-0002
| SYSTEM | |
| Form Factor | 3.5'' SubCompact Board |
| CPU | Intel® Celeron® J6412 (4C/4T, 2.00GHz, 10W) |
| Chipset | Integrated with Intel ® SoC |
| Memory Type | Single-Channel DDR4 3200MHz SODIMM x 1, Max. 32GB, Non-ECC *IBECC supported by selected CPU SKU |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Level |
| Security | TPM 2.0 |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION (L X W) | 5.75" x 4" (146mm x 101.7mm), 0.83 lbs (0.38 kg) |
| OS SUPPORT | Windows 10 (64bit) Linux Ubuntu 20.04.5 / 5.15.0-46-generic |
| POWER | |
| Power Requirement | +12V |
| Power Supply Type | AT/ATX |
| Power Connector | Phoenix 2-pin Connector |
| Power Consumption | Intel Atom® x6413E, DDR4 32GB, 2.17A @+12V (Typical) Intel Atom® x6413E, DDR4 32GB, 2.72A @+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | Dual-Channel 18/24-bit LVDS x 1, up to 1920 x 1080 eDP 1.3 x 1, up to 1920 x 1200 (Optional) |
| Display Interface | HDMI 1.4 x 1, up to 3840 x 2160 @ 30Hz DP 1.4 x 1, up to 3840 x 2160 @ 120Hz |
| MULTIPLE DISPLAY | Up to 3 Simultaneous Displays |
| AUDIO | |
| CODEC | REALTEK ALC897 |
| AUDIO INTERFACE | Line-in/Line-out/MIC |
| SPEAKER | — |
| EXTERNAL I/O | |
| ETHERNET | Realtek RTL8111H 1GbE, RJ-45 x 2 |
| USB | USB3.2 Gen 2 x 2 |
| VIDEO | HDMI 1.4 x 1, DP1.4 x 1 |
| INTERNAL I/O | |
| USB | USB2.0 x 4 |
| SERIAL PORT | COM1 (RS232/422/485, supports 5V/12V/RI) COM2 (RS232) |
| VIDEO | LVDS / eDP x 1 (Default: LVDS) Inverter x 1 (12V/2A) |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio Header x 1 |
| DIO/GPIO | GPIO 8-bits |
| SMBUS/I2C | SMBus / I2C x 1 (Default: SMBus) |
| TOUCH | 4/5/8-wire Touch Controller x 1 |
| FAN | 4pins Smart Fan x 1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| Mini PCI-E/mSATA | Full-size mPCIe x 1 |
| M.2 | M.2 2230 E-Key x 1 (PCIe 3.0 [x1], USB2.0) M.2 2280 M-Key x 1 (PCIe 3.0 [x2] / SATA), SATA select by BOM |
| ENVIRONMENT & CERTIFICATION | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 484,355 |
| Certification | CE/FCC Class A |
GENE-EHL7-A10-0003
| SYSTEM | |
| Form Factor | 3.5'' SubCompact Board |
| CPU | Intel® Atom® x6413E (4C/4T, 1.50GHz, 9W) |
| Chipset | Integrated with Intel ® SoC |
| Memory Type | Single-Channel DDR4 3200MHz SODIMM x 1, Max. 32GB, Non-ECC *IBECC supported by selected CPU SKU |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Level |
| Security | TPM 2.0 |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION (L X W) | 5.75" x 4" (146mm x 101.7mm), 0.83 lbs (0.38 kg) |
| OS SUPPORT | Windows 10 (64bit) Linux Ubuntu 20.04.5 / 5.15.0-46-generic |
| POWER | |
| Power Requirement | +12V |
| Power Supply Type | AT/ATX |
| Power Connector | Phoenix 2-pin Connector |
| Power Consumption | Intel Atom® x6413E, DDR4 32GB, 2.17A @+12V (Typical) Intel Atom® x6413E, DDR4 32GB, 2.72A @+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | Dual-Channel 18/24-bit LVDS x 1, up to 1920 x 1080 eDP 1.3 x 1, up to 1920 x 1200 (Optional) |
| Display Interface | HDMI 1.4 x 1, up to 3840 x 2160 @ 30Hz DP 1.4 x 1, up to 3840 x 2160 @ 120Hz |
| MULTIPLE DISPLAY | Up to 3 Simultaneous Displays |
| AUDIO | |
| CODEC | REALTEK ALC897 |
| AUDIO INTERFACE | Line-in/Line-out/MIC |
| SPEAKER | — |
| EXTERNAL I/O | |
| ETHERNET | Realtek RTL8111H 1GbE, RJ-45 x 2 |
| USB | USB3.2 Gen 2 x 2 |
| VIDEO | HDMI 1.4 x 1, DP1.4 x 1 |
| INTERNAL I/O | |
| USB | USB2.0 x 4 |
| SERIAL PORT | COM1 (RS232/422/485, supports 5V/12V/RI) COM2 (RS232) |
| VIDEO | LVDS / eDP x 1 (Default: LVDS) Inverter x 1 (12V/2A) |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio Header x 1 |
| DIO/GPIO | GPIO 8-bits |
| SMBUS/I2C | SMBus / I2C x 1 (Default: SMBus) |
| TOUCH | 4/5/8-wire Touch Controller x 1 |
| FAN | 4pins Smart Fan x 1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| Mini PCI-E/mSATA | Full-size mPCIe x 1 |
| M.2 | M.2 2230 E-Key x 1 (PCIe 3.0 [x1], USB2.0) M.2 2280 M-Key x 1 (PCIe 3.0 [x2] / SATA), SATA select by BOM |
| ENVIRONMENT & CERTIFICATION | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 484,355 |
| Certification | CE/FCC Class A |
- GENE-EHL7 MB x 1
