GENE-EHL5
SubCompact Board with Intel Atom® x6000E Series, and Intel® Pentium® and Celeron® N and J Series Processors
As low as
US$302.00
Availability:
In stock
Inventory: please select an item
SKU
GENE-EHL5
GENE-EHL5 is a 3.5” subcompact board made to meet the next-generation edge applications in the 5G era. Powered by Intel® Atom™ x6000E Series, Pentium® and Celeron® N and J series processors (formerly Elkhart Lake), GENE-EHL5 delivers up to 40% greater performance than previous generation platforms. Designed as the next-generation subcompact board, GENE-EHL5 comes with revolutionary board design which provides four M.2 expansion slots, doubling the previous generations. In fact, one of the M.2 slots supports 5G network module. To further its 5G connectivity, GENE-EHL5 is designed with a nano SIM slot compatible with 5G network. To meet the optimal balance of performance and budget, GENE-EHL5 comes with DDR4 SO-DIMM up to 32GB, offering higher flexibility and scalability than onboard memory. For reliable Ethernet connection in outdoor edge computing, GENE-EHL5 comes with dual Intel® i210 GbE Ethernet controllers for robust industrial LAN connectivity. For IoV (Internet of Vehicles) or telematics applications, GENE-EHL5 provides dual CANBUS channels allowing the implementations of smart vehicle software.
Note: The features of different SKUs may vary. Please check the product specifications before making your purchase.
GENE-EHL5-A10-0005
| SYSTEM | |
| Form Factor | 3.5" SubCompact Board |
| CPU | Intel® Pentium® Processor J6426 (4C/4T, 2.00 GHz, 10W) |
| Chipset | Integrated with Intel® SoC |
| Memory Type | DDR4 3200, Single Channel SODIMM x 1, Max. 32GB, Non-ECC *IBECC supported by selected CPU SKU |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Level |
| Security | TPM 2.0 |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION (L X W) | 5.75" x 4" (146mm x 101.7mm), 1.10 lbs (0.50 kg) |
| OS SUPPORT | Windows 10 (64bit) Linux Ubuntu 20.04.3(IOT)/Kernel 5.13 |
| POWER | |
| Power Requirement | +9V~36V |
| Power Supply Type | AT/ATX |
| Power Connector | Phoenix 2-pin Connector |
| Power Consumption | Intel Atom® x6425E, DDR4 32GB, 3.06A @+12V (Typical) Intel Atom® x6425E, DDR4 32GB, 3.49A @+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | LVDS x 1, Dual Channel 18/24bit, up to 1920 x 1080 |
| Display Interface | HDMI 2.0 x 1, up to 3840 x 2160@60Hz DP 1.4 x 1, up to 3840 x 2160@120Hz (support DP++) |
| AUDIO | |
| CODEC | Realtek ALC269 |
| AUDIO INTERFACE | Line-In/Line-Out/Mic |
| SPEAKER | 2W Speaker |
| EXTERNAL I/O | |
| ETHERNET | Intel® I210 1GbE, RJ45 x 2 |
| USB | USB 3.2 Gen 2 x 2 |
| VIDEO | HDMI 2.0 x 1 DP 1.4 x 1 |
| INTERNAL I/O | |
| USB | USB 2.0 x 4 |
| SERIAL PORT | COM 1, COM 4 (RS-232/422/485) COM 2, COM 3 (RS-232/422/485, supports 5V/12V/RI) |
| VIDEO | LVDS x 1 |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio Header x 1 |
| DIO/GPIO | GPIO 16-bits (8 In / 8 Out) |
| SMBUS/I2C | SMBus/I2C x 1 (Default: SMBus) |
| TOUCH | 4/5/8 wire Touch Controller x 1 |
| FAN | 4pins Smart Fan x 1 |
| SIM | Nano SIM x 1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| OTHERS | CANBUS x 2 |
| EXPANSION | |
| EXPANSION SLOT | M.2 2230 E-Key x 1 (PCIe 3.0 [x1], USB 2.0) M.2 2242 B-Key x 1 (PCIe 3.0 [x2]/SATA, Default: PCIe [x2]) M.2 2280 B-Key x 1 (PCIe 3.0 [x1], USB 2.0, PCIe 3.0 [x2] select by BIOS) M.2 3052 B-Key x 1 (USB 3.2 Gen 2, USB2.0) |
| ENVIRONMENT & CERTIFICATION | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 335,427 |
| Certification | CE/FCC Class A |
GENE-EHL5-A10-0003
| SYSTEM | |
| Form Factor | 3.5" SubCompact Board |
| CPU | Intel® Celeron® Processor J6412 (4C/4T, 2.00 GHz, 10W) |
| Chipset | Integrated with Intel ® SoC |
| Memory Type | DDR4 3200, Single Channel SODIMM x 1, Max. 32GB, Non-ECC *IBECC supported by selected CPU SKU |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Level |
| Security | TPM 2.0 |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION (L X W) | 5.75" x 4" (146mm x 101.7mm), 1.10 lbs (0.50 kg) |
| OS SUPPORT | Windows 10 (64bit) Linux Ubuntu 20.04.3(IOT)/Kernel 5.13 |
| POWER | |
| Power Requirement | +9V~36V |
| Power Supply Type | AT/ATX |
| Power Connector | Phoenix 2-pin Connector |
| Power Consumption | Intel Atom® x6425E, DDR4 32GB, 3.06A @+12V (Typical) Intel Atom® x6425E, DDR4 32GB, 3.49A @+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | LVDS x 1, Dual Channel 18/24bit, up to 1920 x 1080 |
| Display Interface | HDMI 2.0 x 1, up to 3840 x 2160@60Hz DP 1.4 x 1, up to 3840 x 2160@120Hz (support DP++) |
| AUDIO | |
| CODEC | Realtek ALC269 |
| AUDIO INTERFACE | Line-In/Line-Out/Mic |
| SPEAKER | 2W Speaker |
| EXTERNAL I/O | |
| ETHERNET | Intel® I210 1GbE, RJ45 x 2 |
| USB | USB 3.2 Gen 2 x 2 |
| VIDEO | HDMI 2.0 x 1 DP 1.4 x 1 |
| INTERNAL I/O | |
| USB | USB 2.0 x 4 |
| SERIAL PORT | COM 1, COM 4 (RS-232/422/485) COM 2, COM 3 (RS-232/422/485, supports 5V/12V/RI) |
| VIDEO | LVDS x 1 |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio Header x 1 |
| DIO/GPIO | GPIO 16-bits (8 In / 8 Out) |
| SMBUS/I2C | SMBus/I2C x 1 (Default: SMBus) |
| TOUCH | 4/5/8 wire Touch Controller x 1 |
| FAN | 4pins Smart Fan x 1 |
| SIM | Nano SIM x 1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| OTHERS | eMMC5.1 32GB |
| EXPANSION | |
| EXPANSION SLOT | M.2 2230 E-Key x 1 (PCIe 3.0 [x1], USB 2.0) M.2 2242 B-Key x 1 (PCIe 3.0 [x2]/SATA, Default: PCIe [x2]) M.2 2280 B-Key x 1 (PCIe 3.0 [x1], USB 2.0, PCIe 3.0 [x2] select by BIOS) M.2 3052 B-Key x 1 (USB 3.2 Gen 2, USB2.0) |
| ENVIRONMENT & CERTIFICATION | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 335,427 |
| Certification | CE/FCC Class A |
GENE-EHL5-A10-0007
| SYSTEM | |
| Form Factor | 3.5" SubCompact Board |
| CPU | Intel Atom® x6425E (4C/4T, 2.00 GHz, 12W) |
| Chipset | Integrated with Intel® SoC |
| Memory Type | DDR4 3200, Single Channel SODIMM x 1, Max. 32GB, Non-ECC *IBECC supported by selected CPU SKU |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Level |
| Security | TPM 2.0 |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION (L X W) | 5.75" x 4" (146mm x 101.7mm), 1.10 lbs (0.50 kg) |
| OS SUPPORT | Windows 10 (64bit) Linux Ubuntu 20.04.3(IOT)/Kernel 5.13 |
| POWER | |
| Power Requirement | +9V~36V |
| Power Supply Type | AT/ATX |
| Power Connector | Phoenix 2-pin Connector |
| Power Consumption | Intel Atom® x6425E, DDR4 32GB, 3.06A @+12V (Typical) Intel Atom® x6425E, DDR4 32GB, 3.49A @+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | LVDS x 1, Dual Channel 18/24bit, up to 1920 x 1080 |
| Display Interface | HDMI 2.0 x 1, up to 3840 x 2160@60Hz DP 1.4 x 1, up to 3840 x 2160@120Hz (support DP++) |
| AUDIO | |
| CODEC | Realtek ALC269 |
| AUDIO INTERFACE | Line-In/Line-Out/Mic |
| SPEAKER | 2W Speaker |
| EXTERNAL I/O | |
| ETHERNET | Intel® I210 1GbE, RJ45 x 2 |
| USB | USB 3.2 Gen 2 x 2 |
| VIDEO | HDMI 2.0 x 1 DP 1.4 x 1 |
| INTERNAL I/O | |
| USB | USB 2.0 x 4 |
| SERIAL PORT | COM 1, COM 4 (RS-232/422/485) COM 2, COM 3 (RS-232/422/485, supports 5V/12V/RI) |
| VIDEO | LVDS x 1 |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio Header x 1 |
| DIO/GPIO | GPIO 16-bits (8 In / 8 Out) |
| SMBUS/I2C | SMBus/I2C x 1 (Default: SMBus) |
| TOUCH | 4/5/8 wire Touch Controller x 1 |
| FAN | 4pins Smart Fan x 1 |
| SIM | Nano SIM x 1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| OTHERS | eMMC5.1 32GB CANBUS x 2, TX/RX |
| EXPANSION | |
| EXPANSION SLOT | M.2 2230 E-Key x 1 (PCIe 3.0 [x1], USB 2.0) M.2 2242 B-Key x 1 (PCIe 3.0 [x2]/SATA, Default: PCIe [x2]) M.2 2280 B-Key x 1 (PCIe 3.0 [x1], USB 2.0, PCIe 3.0 [x2] select by BIOS) M.2 3052 B-Key x 1 (USB 3.2 Gen 2, USB2.0) |
| ENVIRONMENT & CERTIFICATION | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 335,427 |
| Certification | CE/FCC Class A |
GENE-EHL5-A10-0006
| SYSTEM | |
| Form Factor | 3.5" SubCompact Board |
| CPU | Intel Atom® x6211E (2C/2T, 1.30 GHz, 6W) |
| Chipset | Integrated with Intel® SoC |
| Memory Type | DDR4 3200, Single Channel SODIMM x 1, Max. 32GB, Non-ECC *IBECC supported by selected CPU SKU |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Level |
| Security | — |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION (L X W) | 5.75" x 4" (146mm x 101.7mm), 1.10 lbs (0.50 kg) |
| OS SUPPORT | Windows 10 (64bit) Linux Ubuntu 20.04.3(IOT)/Kernel 5.13 |
| POWER | |
| Power Requirement | +12V |
| Power Supply Type | AT/ATX |
| Power Connector | Phoenix 2-pin Connector |
| Power Consumption | Intel Atom® x6425E, DDR4 32GB, 3.06A @+12V (Typical) Intel Atom® x6425E, DDR4 32GB, 3.49A @+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | LVDS x 1, Dual Channel 18/24bit, up to 1920 x 1080 |
| Display Interface | HDMI 2.0 x 1, up to 3840 x 2160@60Hz DP 1.4 x 1, up to 3840 x 2160@120Hz (support DP++) |
| AUDIO | |
| CODEC | Realtek ALC269 |
| AUDIO INTERFACE | Line-In/Line-Out/Mic |
| SPEAKER | 2W Speaker |
| EXTERNAL I/O | |
| ETHERNET | Intel® I210 1GbE, RJ45 x 2 |
| USB | USB 3.2 Gen 2 x 2 |
| VIDEO | HDMI 2.0 x 1 DP 1.4 x 1 |
| INTERNAL I/O | |
| USB | USB 2.0 x 4 |
| SERIAL PORT | COM 1, COM 4 (RS-232/422/485) COM 2, COM 3 (RS-232/422/485, supports 5V/12V/RI) |
| VIDEO | LVDS x 1 |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio Header x 1 |
| DIO/GPIO | GPIO 16-bits (8 In / 8 Out) |
| SMBUS/I2C | SMBus/I2C x 1 (Default: SMBus) |
| TOUCH | — |
| FAN | 4pins Smart Fan x 1 |
| SIM | Nano SIM x 1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| EXPANSION SLOT | M.2 2230 E-Key x 1 (PCIe 3.0 [x1], USB 2.0) M.2 2242 B-Key x 1 (PCIe 3.0 [x2]/SATA, Default: PCIe [x2]) M.2 2280 B-Key x 1 (PCIe 3.0 [x1], USB 2.0, PCIe 3.0 [x2] select by BIOS) M.2 3052 B-Key x 1 (USB 3.2 Gen 2, USB2.0) |
| ENVIRONMENT & CERTIFICATION | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 335,427 |
| Certification | CE/FCC Class A |
GENE-EHL5-A10-0009
| SYSTEM | |
| Form Factor | 3.5" SubCompact Board |
| CPU | Intel Atom® x6425RE (4C/4T, 1.90 GHz, 12W) |
| Chipset | Integrated with Intel® SoC |
| Memory Type | DDR4 3200, Single Channel SODIMM x 1, Max. 32GB, Non-ECC *IBECC supported by selected CPU SKU |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Level |
| Security | TPM 2.0 |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION (L X W) | 5.75" x 4" (146mm x 101.7mm), 1.10 lbs (0.50 kg) |
| OS SUPPORT | Windows 10 (64bit) Linux Ubuntu 20.04.3(IOT)/Kernel 5.13 |
| POWER | |
| Power Requirement | +9V~36V |
| Power Supply Type | AT/ATX |
| Power Connector | Phoenix 2-pin Connector |
| Power Consumption | Intel Atom® x6425E, DDR4 32GB, 3.06A @+12V (Typical) Intel Atom® x6425E, DDR4 32GB, 3.49A @+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | LVDS x 1, Dual Channel 18/24bit, up to 1920 x 1080 |
| Display Interface | HDMI 2.0 x 1, up to 3840 x 2160@60Hz DP 1.4 x 1, up to 3840 x 2160@120Hz (support DP++) |
| AUDIO | |
| CODEC | Realtek ALC269 |
| AUDIO INTERFACE | Line-In/Line-Out/Mic |
| SPEAKER | 2W Speaker |
| EXTERNAL I/O | |
| ETHERNET | Intel® I210 1GbE, RJ45 x 2 |
| USB | USB 3.2 Gen 2 x 2 |
| VIDEO | HDMI 2.0 x 1 DP 1.4 x 1 |
| INTERNAL I/O | |
| USB | USB 2.0 x 4 |
| SERIAL PORT | COM 1, COM 4 (RS-232/422/485) COM 2, COM 3 (RS-232/422/485, supports 5V/12V/RI) |
| VIDEO | LVDS x 1 |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio Header x 1 |
| DIO/GPIO | GPIO 16-bits (8 In / 8 Out) |
| SMBUS/I2C | SMBus/I2C x 1 (Default: SMBus) |
| TOUCH | 4/5/8 wire Touch Controller x 1 |
| FAN | 4pins Smart Fan x 1 |
| SIM | Nano SIM x 1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| OTHERS | CANBUS x 2 |
| EXPANSION | |
| EXPANSION SLOT | M.2 2230 E-Key x 1 (PCIe 3.0 [x1], USB 2.0) M.2 2242 B-Key x 1 (PCIe 3.0 [x2]/SATA, Default: PCIe [x2]) M.2 2280 B-Key x 1 (PCIe 3.0 [x1], USB 2.0, PCIe 3.0 [x2] select by BIOS) M.2 3052 B-Key x 1 (USB 3.2 Gen 2, USB2.0) |
| ENVIRONMENT & CERTIFICATION | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 335,427 |
| Certification | CE/FCC Class A |
GENE-EHL5-A10-0002
| SYSTEM | |
| Form Factor | 3.5" SubCompact Board |
| CPU | Intel® Celeron® Processor N6210 (2C/2T, 1.20 GHz, 6.5W) |
| Chipset | Integrated with Intel® SoC |
| Memory Type | DDR4 3200, Single Channel SODIMM x 1, Max. 32GB, Non-ECC *IBECC supported by selected CPU SKU |
| BIOS | UEFI |
| Wake on LAN | Yes |
| Watchdog Timer | 255 Level |
| Security | — |
| RTC BATTERY | Lithium Battery 3V/240mAh |
| DIMENSION (L X W) | 5.75" x 4" (146mm x 101.7mm), 1.10 lbs (0.50 kg) |
| OS SUPPORT | Windows 10 (64bit) Linux Ubuntu 20.04.3(IOT)/Kernel 5.13 |
| POWER | |
| Power Requirement | +12V |
| Power Supply Type | AT/ATX |
| Power Connector | Phoenix 2-pin Connector |
| Power Consumption | Intel Atom® x6425E, DDR4 32GB, 3.06A @+12V (Typical) Intel Atom® x6425E, DDR4 32GB, 3.49A @+12V (Max) |
| DISPLAY | |
| CONTROLLER | Intel® UHD Graphics for 10th Gen Intel® Processors |
| LVDS/EDP | LVDS x 1, Dual Channel 18/24bit, up to 1920 x 1080 |
| Display Interface | VGA x 1, up to 2560 x 1440 |
| AUDIO | |
| CODEC | Realtek ALC269 |
| AUDIO INTERFACE | Line-In/Line-Out/Mic |
| SPEAKER | 2W Speaker |
| EXTERNAL I/O | |
| ETHERNET | Intel® I210 1GbE, RJ45 x 2 |
| USB | USB 3.2 Gen 2 x 2 |
| VIDEO | VGA x 1 |
| INTERNAL I/O | |
| USB | USB 2.0 x 4 |
| SERIAL PORT | COM 1, COM 4 (RS-232/422/485) COM 2, COM 3 (RS-232/422/485, supports 5V/12V/RI) |
| VIDEO | LVDS x 1 |
| SATA | SATA 6.0 Gb/s x 1 +5V SATA Power Connector x 1 |
| AUDIO | Audio Header x 1 |
| DIO/GPIO | GPIO 16-bits (8 In / 8 Out) |
| SMBUS/I2C | SMBus/I2C x 1 (Default: SMBus) |
| TOUCH | — |
| FAN | 4pins Smart Fan x 1 |
| SIM | Nano SIM x 1 |
| FRONT PANEL | HDD LED, PWR LED, Power Button, Buzzer, Reset |
| EXPANSION | |
| EXPANSION SLOT | M.2 2230 E-Key x 1 (PCIe 3.0 [x1], USB 2.0) M.2 2242 B-Key x 1 (PCIe 3.0 [x2]/SATA, Default: PCIe [x2]) M.2 2280 B-Key x 1 (PCIe 3.0 [x1], USB 2.0, PCIe 3.0 [x2] select by BIOS) M.2 3052 B-Key x 1 (USB 3.2 Gen 2, USB2.0) |
| ENVIRONMENT & CERTIFICATION | |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF (hours) | 335,427 |
| Certification | CE/FCC Class A |
- GENE-EHL5 MB x 1
- M16BT07020 (Heatsink) x 1
The Latest NVIDIA Jetson Orin Platform Solutions (Fast Delivery!)
- BOXER-8641AIAI@Edge Compact Fanless Embedded AI System with NVIDIA® Jetson AGX Orin™As low as US$2,600.00
-
-
-
