GENE-ADN6

3.5" SubCompact Board with Intel Processor N Series, Intel Core i3-N305 Processors
As low as US$315.00
Availability: In stock
Inventory: please select an item
SKU
GENE-ADN6
  • Intel® N series, and Intel® CoreTM i3-N305 Processors
  • DDR5 4800 MHz, SODIMM x 1, Up to 16GB
  • HDMI 1.4, VGA, LVDS x 1
  • Intel 2.5GbE x 3, SATA 6.0 Gb/s x 1, GPIO x 8bit
  • USB3.2 Gen2 x 2, USB2.0 x 4, RS-232/422/485 x 2, RS-232 x 2
  • Mini PCIe card x 1, M.2 E-Key 2230 x 1, M.2 B-Key 3052 x 1
  • Wide DC Input 9-36V

Note: To achieve the best performance, it is recommended that you order the Heat sink together with the GENE-ADN6.

The new GENE-ADN6 seamlessly combines durability with sophistication. A densely populated 3.5" SubCompact Board powered by Intel Atom® x7000E Series, Intel® Processor N Series, and Intel® Core™ i3-N305 Processors, the GENE-ADN6 offers a wealth of features tailored for machine vision, drone, and AMR applications. With wide temperature support, diverse peripheral device integration, three simultaneous display outputs, and compatibility with multiple communication protocols, the GENE-ADN6 provides all the essential components necessary to bring sophisticated projects to market across various industries.

GENE-ADN6-A10-0002
SYSTEM
Form Factor 3.5" SubCompact Board
CPU Intel® Processor N97 (4C/4T, up to 3.6 GHz, 12W)
Chipset Integrated with Intel® SoC
Memory Type DDR5 4800, Single Channel SODIMM x 1, Max.16GB, Non-ECC
BIOS UEFI
Wake on LAN Yes
Watchdog Timer 255 Levels
Security TPM 2.0
RTC Battery Lithium Battery 3V/240mAH
Dimensions 5.75" x 4" (146mm x 101.7mm), 0.94 lbs (0.43 kg)
OS Support Windows 10 (64bit)
Ubuntu 22.04 / Kernel 5.15.0-25-generic
Power
Power Requirement +9V~36V
Power Supply Type AT/ATX
Connector Phoeix 2-pin Connector
Power Consumption Intel® Core™ i3-N305,16GB x 1, 3.80A@ +12V (TYPICAL)
Intel® Core™ i3-N305, 16GB x 1, 5.48A@ +12V (MAX)
Display
Controller Intel® UHD Graphics
LVDS/eDP LVDS x 1, Dual Channel 18/24bit, up to 1920 x1080
Display Interface HDMI 1.4 x 1, up to 3840 x2160 @30Hz
VGA x 1, up to 1920 x1080
Multiple Display Up to 3 Simultaneous Displays
Audio
Codec Realtek ALC897
Audio Interface Line-In / Line-Out / Mic
Speaker
EXTERNAL I/O
Ethernet Intel® i226 2.5G, RJ-45 x 3
USB USB3.2 Gen 2 x 2
Serial Port
Video HDMI 1.4 x 1, VGA x 1
INTERNAL I/O
USB USB2.0 x 4
Serial Port COM1 , COM2 (RS232/422/485,supports 5V/12V/RI)
COM3 , COM4 (RS232)
Video LVDS x 1, Inverter x 1 (12V/2A)
SATA SATA 6.0 Gb/s x 1
+5V SATA Power Connector x 1
Audio Audio Header x 1 (Optional)
DIO/GPIO GPIO 8-bit
SMBus/I2C SMBus / I2C x 1 (Default: SMBus)
Touch
Fan 4pins Smart Fan x 1
Sim Nano SIM x 1
Front Panel HDD LED, PWR LED, Power Button, Buzzer, Reset
EXPANSION
MINI PCI-E/MSATA Full-size mSATA / mPCIe x 1 (Default: mSATA, select by BIOS)
M.2 M.2 2230 E-Key x 1 (PCIe 3.0 [x1] + USB2.0)
M.2 3052 B-Key x 1 (USB3.2 Gen2 + USB2.0)
ENVIRONMENT & CERTIFICATION
Operating Temp. -4°F ~ 158°F (-20°C ~ 70°C)
Storage Temp. -40°F ~ 185°F (-40°C ~ 85°C)
Operating Humidity 0% ~ 90% relative humidity, non-condensing
MTBF (Hours) 337,963
EMC CE/FCC Class A
GENE-ADN6-A10-0004
SYSTEM
Form Factor 3.5" SubCompact Board
CPU Intel® Core™ i3-N305 (8C/8T, up to 3.8 GHz, 15W)
Chipset Integrated with Intel® SoC
Memory Type DDR5 4800, Single Channel SODIMM x 1, Max.16GB, Non-ECC
BIOS UEFI
Wake on LAN Yes
Watchdog Timer 255 Levels
Security TPM 2.0
RTC Battery Lithium Battery 3V/240mAH
Dimensions 5.75" x 4" (146mm x 101.7mm), 0.94 lbs (0.43 kg)
OS Support Windows 10 (64bit)
Ubuntu 22.04 / Kernel 5.15.0-25-generic
Power
Power Requirement +9V~36V
Power Supply Type AT/ATX
Connector Phoeix 2-pin Connector
Power Consumption Intel® Core™ i3-N305,16GB x 1, 3.80A@ +12V (TYPICAL)
Intel® Core™ i3-N305, 16GB x 1, 5.48A@ +12V (MAX)
Display
Controller Intel® UHD Graphics
LVDS/eDP LVDS x 1, Dual Channel 18/24bit, up to 1920 x1080
Display Interface HDMI 1.4 x 1, up to 3840 x2160 @30Hz
VGA x 1, up to 1920 x1080
Multiple Display Up to 3 Simultaneous Displays
Audio
Codec Realtek ALC897
Audio Interface Line-In / Line-Out / Mic
Speaker
EXTERNAL I/O
Ethernet Intel® i226 2.5G, RJ-45 x 3
USB USB3.2 Gen 2 x 2
Serial Port
Video HDMI 1.4 x 1, VGA x 1
INTERNAL I/O
USB USB2.0 x 4
Serial Port COM1 , COM2 (RS232/422/485,supports 5V/12V/RI)
COM3 , COM4 (RS232)
Video LVDS x 1, Inverter x 1 (12V/2A)
SATA SATA 6.0 Gb/s x 1
+5V SATA Power Connector x 1
Audio Audio Header x 1 (Optional)
DIO/GPIO GPIO 8-bit
SMBus/I2C SMBus / I2C x 1 (Default: SMBus)
Touch
Fan 4pins Smart Fan x 1
Sim Nano SIM x 1
Front Panel HDD LED, PWR LED, Power Button, Buzzer, Reset
EXPANSION
MINI PCI-E/MSATA Full-size mSATA / mPCIe x 1 (Default: mSATA, select by BIOS)
M.2 M.2 2230 E-Key x 1 (PCIe 3.0 [x1] + USB2.0)
M.2 3052 B-Key x 1 (USB3.2 Gen2 + USB2.0)
ENVIRONMENT & CERTIFICATION
Operating Temp. -4°F ~ 158°F (-20°C ~ 70°C)
Storage Temp. -40°F ~ 185°F (-40°C ~ 85°C)
Operating Humidity 0% ~ 90% relative humidity, non-condensing
MTBF (Hours) 337,963
EMC CE/FCC Class A
GENE-ADN6-A10-0001
SYSTEM
Form Factor 3.5" SubCompact Board
CPU Intel® Processor N50 (2C/2T, up to 3.4 GHz, 6W)
Chipset Integrated with Intel® SoC
Memory Type DDR5 4800, Single Channel SODIMM x 1, Max.16GB, Non-ECC
BIOS UEFI
Wake on LAN Yes
Watchdog Timer 255 Levels
Security TPM 2.0
RTC Battery Lithium Battery 3V/240mAH
Dimensions 5.75" x 4" (146mm x 101.7mm), 0.94 lbs (0.43 kg)
OS Support Windows 10 (64bit)
Ubuntu 22.04 / Kernel 5.15.0-25-generic
Power
Power Requirement +9V~36V
Power Supply Type AT/ATX
Connector Phoeix 2-pin Connector
Power Consumption Intel® Core™ i3-N305,16GB x 1, 3.80A@ +12V (TYPICAL)
Intel® Core™ i3-N305, 16GB x 1, 5.48A@ +12V (MAX)
Display
Controller Intel® UHD Graphics
LVDS/eDP LVDS x 1, Dual Channel 18/24bit, up to 1920 x1080
Display Interface HDMI 1.4 x 1, up to 3840 x2160 @30Hz
VGA x 1, up to 1920 x1080
Multiple Display Up to 3 Simultaneous Displays
Audio
Codec Realtek ALC897
Audio Interface Line-In / Line-Out / Mic
Speaker
EXTERNAL I/O
Ethernet Intel® i226 2.5G, RJ-45 x 3
USB USB3.2 Gen 2 x 2
Serial Port
Video HDMI 1.4 x 1, VGA x 1
INTERNAL I/O
USB USB2.0 x 4
Serial Port COM1 , COM2 (RS232/422/485,supports 5V/12V/RI)
COM3 , COM4 (RS232)
Video LVDS x 1, Inverter x 1 (12V/2A)
SATA SATA 6.0 Gb/s x 1
+5V SATA Power Connector x 1
Audio Audio Header x 1(Optional)
DIO/GPIO GPIO 8-bit
SMBus/I2C SMBus / I2C x 1 (Default: SMBus)
Touch
Fan 4pins Smart Fan x 1
Sim Nano SIM x 1
Front Panel HDD LED, PWR LED, Power Button, Buzzer, Reset
EXPANSION
MINI PCI-E/MSATA Full-size mSATA / mPCIe x 1 (Default: mSATA, select by BIOS)
M.2 M.2 2230 E-Key x 1 (PCIe 3.0 [x1] + USB2.0)
M.2 3052 B-Key x 1 (USB3.2 Gen2 + USB2.0)
ENVIRONMENT & CERTIFICATION
Operating Temp. -4°F ~ 158°F (-20°C ~ 70°C)
Storage Temp. -40°F ~ 185°F (-40°C ~ 85°C)
Operating Humidity 0% ~ 90% relative humidity, non-condensing
MTBF (Hours) 337,963
EMC CE/FCC Class A
  • GENE-ADN6 MB x 1



Optional Accessories
Item DESCRIPTION

Heat Sink

Cooler or heatsink is not included in the packing list.
Please click HERE if you'd like to add it to your order.
