FWS-2290

Network Appliance with Intel® Processor N97
US$427.00
Availability: In stock
Only 3 left
SKU
FWS-2290-E4-A10-000

  • Intel® Processor N-series, 2~8 cores
  • Onboard LPDDR5 4GB, up to 16GB
  • Intel® Ethernet Controller I226-V, 2.5GbE x 4
  • M.2 3052 B-Key for 5G (Co-lay Mini-Card slot with Push-pin SIM for 4G LTE/Wi-Fi)
  • M.2 2230 E-Key (Co–lay Mini-Card slot for Wi-Fi)

Implement network security solutions you can trust with the new FWS-2290. AAEON's most powerful desktop network platform yet, the FWS-2290 offers Intel® Processor N-series processing alongside the most advanced selection of networking interfaces its desktop network appliance portfolio has ever seen, giving enterprises of all sizes the ultimate toolset with which to manage their network traffic, security, and connectivity.

Up to 8 Cores of Efficient Computing

Utilizing the Intel® Processor N97 CPU, and supporting the full Intel® Processor N-series range, the FWS-2290 grants up to 8 cores of computing power at just 15W. Additionally, the platform offers integrated security for applications such as UTM and VPN through the inclusion of Intel® Control-Flow Enforcement Technology (CET), AES-NI, and Virtualization Technology for Directed I/O, accelerating encryption and decryption and reinforcing software vulnerabilities when managing large volumes of network traffic.

Faster, More Robust Networking

The FWS-2290 boasts four LAN ports supporting Intel® Ethernet Controller I226-V at 2.5GbE with LAN bypass, granting multiple avenues for fast, reliable wired connectivity. Moreover, the device's onboard LPDDR5 provides greater speed and lower latency, facilitating the parallel data processing required by firewall, VPN, and intrusion detection applications without impacting network throughput.

Modular Wireless Expansion

The expansion offered by the FWS-2290 open the door to more flexible networking solutions, with M.2 E and B-Key slots providing both Wi-Fi and 5G support, in addition to a co-layed mini card for 4G/LTE connectivity. Such multifaceted options increase robustness and redundancy-proofing, while the device also houses up to six openings for the installation of external antennas, substantially boosting both signal strength and range.

SYSTEM
FORM FACTOR Desktop Network Appliance
PROCESSOR Intel® Processor N97
CHIPSET SoC
SYSTEM MEMORY Onboard 4G LPDDR5
NETWORK
ETHERNET Intel® Ethernet Controller I226-V, 2.5GbE x 4
BYPASS 1 Pair
DISPLAY
GRAPHICS CONTROLLER Intel® UHD Graphics
CONNECTOR HDMI x 1 (Optional)
STORAGE
HDD 2.5" HDD Bay x 1
CF/CFAST/MSATA 32G eMMC
SATA 6Gb/s x 1
INTERNAL/ EXPANSION INTERFACE
PCIE SLOT
MINI-PCIE SLOT M.2 3052 B-Key (5G, Colay Mini Card with Push-pin SIM for 4G LTE/Wi-Fi)
M.2 2230 E-Key (Colay Mini Card slot for Wi-Fi)
Keyboard and Mouse
USB USB 3.2 Gen 2 x 1
USB 2.0 x 1
MISCELLANEOUS
RTC Internal RTC
WATCHDOG TIMER 1~255 steps by software programmable
Software Button GPIO Programmable push button x 1
TPM (TPM 2.0 SLB9670 VQ2.0 FW7.85, optional)
GPIO 4-bit Input, 4-bit Output (optional)
FAN Fan x 1
MTBF (HOURS) 952,764
COLOR Black
PHYSICAL & ENVIRONMENTAL SPEC
POWER Consumption 12V Lockable DC Power Input Connector x 1 (40W Power Adapter)
OPERATING TEMPERATURE 32°F ~ 104°F (0°C ~ 40°C )
STORAGE TEMPERATURE -4°F ~ 140°F (-20°C ~ 60°C)
OPERATING HUMIDITY 10%~80% relative humidity, non-condensing
STORAGE HUMIDITY 10%~80% @40°C; non-condensing
VIBRATION 0.5 Grms/ 5 ~ 500Hz / operation (mSATA)
1.5 Grms/ 5 ~ 500Hz / non-operation
SHOCK 10 G peak acceleration (11 m sec. duration), operation
20 G peak acceleration (11 m sec. duration), non-operation
DIMENSION (W X D X H) 6.5" x 3.62" x 1.57" (165mm x 92mm x 40mm)
I/O
FRONT PANEL Power LED x 1
Status LED x 1
Bypass LED x 1
Storage Active LED x 1
Ethernet LED x 8
(Accessible SIM slot x 1 Optional)
Antenna Hole x 2 (Right panel)
Antenna Hole x 2 (Left panel)
REAR PANEL Lockable DC Power Input Connector x 1
Power Button x 1
USB 3.2 Gen x 1
USB 2.0 x 1
RJ-45 x 4
RJ-45 Console x 1
Reset Button x 1
Antenna Hole x 2
  • Power Cable x 1
  • SATA Cable x 1
  • Power Adapter
  • FWS-2290
