EPIC-ADN9

EPIC Board with Intel® Processor N Series, and Intel® Core™ i3-N305 Processors
As low as US$317.00
Availability: In stock
Inventory: please select an item
SKU
EPIC-ADN9

  • EPIC Board with Intel® Processor N Series, and Intel® Core™ i3-N305 Processors
  • DDR4 3200MHz SODIMM x 1, up to 16GB
  • HDMI 1.4b x 1, Dual-Channel LVDS x 1, DP x 1
  • Full Sized mSATA x 1 + SATA III x 1
  • Intel® I226-V 2.5GbE x 2 (Up to I226V 2.5GbE x 4 support)
  • USB 3.2 Gen 2 x 2, USB 2.0 x 4
  • M.2 2242 B-Key x 1, NanoSIM x 1
  • COM Port x 6, GPIO 16-bit x 1
  • Supports +9V ~ +24V Wide Voltage Input

Note: To achieve the best performance, it is recommended that you order the Heatsink together with the EPIC-ADN9.

Tailored Processor Selection

Available in models powered by Intel Atom® x7425E, Intel® Core™ i3-N305, or Intel® Processor N97/N50 CPUs, the EPIC-ADN9 allows you to tailor and scale comput ing performance and efficiency to the requirements of various industrial automation and manufacturing processes. As a result, the EPIC-ADN9 is well-equipped to meet the demands of applications such as CNC machining and equipment inspection, which rely on precise task execution, while also providing a cost-effective and energy-efficient solution for less demanding deployments like robotic arms.

Versatile Networking Capabilities

The EPIC-ADN9 offers exceptional connectivity for both wired and wireless networking, both of which are essential for the seamless operation of automated processes. Equipped with up to four physical LAN ports supporting Intel® I226-V running at 2.5GbE, the board facilitates high-speed data acquisition from peripheral devices like cameras and sensors. Furthermore, the board's expansion options, including a full-size mPCIe slot, enable support for wireless networking, facilitating edge-to-cloud communication.

Multifaceted Communication Protocols

Featuring two physical COM ports supporting RS-232/422/485, along with an additional four internal COM connectors with RS-232 capability, the EPIC-ADN9 enables simultaneous connections and data exchange with multiple devices. Moreover, the board's six USB ports and 16-bit GPIO offer the communication protocols essential for smart factory functionality, including sensor monitoring and task execution. The EPIC-ADN9 is also tailored to industrial deployment, with a wide 9V~24V voltage input range and fanless design allowing for smooth operation in harsh environments.

Diverse Display Interface

With a selection of display interfaces, including HDMI 1.4, eDP 1.4, DP 1.2, VGA, and LVDS, the EPIC-ADN9 offers the versatility to create and showcase custom interfaces tailored to specific production lines or tasks. With this configuration, the EPIC-ADN9 can simultaneously support up to three displays, allowing project infrastructure to scale seamlessly according to application complexity using just a single board. The range of interfaces offered also ensures compatibility with legacy equipment, allowing for easier deployment.

EPIC-ADN9-A10-0001
SYSTEM
Form Factor 4" EPIC Board
CPU Intel® Core™ i3-N305 (8C/8T, up to 3.8 GHz, TDP 15W)
Chipset Integrated with Intel® SoC
Memory Type DDR4 3200MHz Single-Channel SODIMM x 1, up to 16GB
BIOS UEFI
Wake on LAN Yes
Watchdog Timer 255 Levels
SECURITY TPM 2.0 (Optional)
RTC BATTERY Lithium Battery 3V/240mA
DIMENSION (L X W) 4.53" x 6.50" (115mm x 165mm)
OS SUPPORT Windows® 10 (64-bit)
Ubuntu 22.04.2 LTS/Kernel 5.19
POWER
Power Requirement +9-24V
Power Supply AT/ATX
CONNECTOR 2-Pin Phoenix Connector
POWER CONSUMPTION Intel® Core™ i3-N305, DDR4 16GB, 1.87A+24V (Typical)
Intel® Core™ i3-N305, DDR4 16GB, 2.66A +24V (Max)
DISPLAY
CONTROLLER Intel® UHD Graphics
LVDS/EDP 24/48-bit Dual-Channel LVDS x 1, up to 1920 x 1080
DISPLAY INTERFACE HDMI 1.4 x 1, up to 3840 x 2160 @30Hz
DP 1.2 x 1, up to 3840 x 2160 @144Hz
MULTIPLE DISPLAY Up to 3 Simultaneous Displays
AUDIO
CODEC Realtek ALC897
AUDIO INTERFACE Line-In / Line-Out / MIC
SPEAKER 5W Speaker
EXTERNAL I/O
ETHERNET I226V 2.5GbE x 4
USB USB 3.2 Gen 2 x 2
SERIAL PORT COM 1, COM 2 (RS-232/422/485, support 5V/12V/RI)
VIDEO HDMI 1.4 x 1
DP 1.2 x 1
INTERNAL I/O
USB USB 2.0 x 4
SERIAL PORT COM 3, COM 4, COM 5, COM 6 (RS-232, support RI only)
VIDEO LVDS x 1
Inverter x 1 (5V/12V@2A)
SATA SATA 6.0Gbps x 1 (Default)
AUDIO Audio Header x 1
DIO/GPIO GPIO 16-bits
SMBUS/I2C SMBus / I2C (Default : SMBus)
TOUCH
FAN 4 Pin Smart Fan
SIM Nano SIM x 1
FRONT I/O PANEL Power Button, Reset Button, Power LED, SATA LED, Buzzer
EXPANSION
MINI PCI-E/MSATA Full Sized mPCIe x 1
Full Sized mSATA x 1
M.2 M.2 2242 B-Key x 1 (PCIe 2.0 [x1] + USB 2.0)
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE 32°F ~ 140°F (0°C ~ 60°C)
STORAGE TEMPERATURE -40°F ~ 185°F (-40°C ~ 85°C)
OPERATING HUMIDITY 0% ~ 90% relative humidity, non-condensing
MTBF (HOURS) 364,565
EMC CE/FCC Class A
EPIC-ADN9-A10-0003
SYSTEM
Form Factor 4" EPIC Board
CPU Intel® Processor N97 (4C/4T, up to 3.6 GHz, TDP 12W)
Chipset Integrated with Intel® SoC
Memory Type DDR4 3200MHz Single-Channel SODIMM x 1, up to 16GB
BIOS UEFI
Wake on LAN Yes
Watchdog Timer 255 Levels
Security TPM 2.0 (Optional)
RTC BATTERY Lithium Battery 3V/240mAh
DIMENSION (L X W) 4.53" x 6.50" (115mm x 165mm)
OS SUPPORT Windows® 10 (64-bit)
Ubuntu 22.04.2 LTS/Kernel 5.19
POWER
Power Requirement +9-24V
Power Supply AT/ATX
CONNECTOR 2-Pin Phoenix Connector
POWER CONSUMPTION Intel® Core™ i3-N305, DDR4 16GB, 1.87A+24V (Typical)
Intel® Core™ i3-N305, DDR4 16GB, 2.66A +24V (Max)
DISPLAY
CONTROLLER Intel® UHD Graphics
LVDS/EDP 24/48-bit Dual-Channel LVDS x 1, up to 1920 x 1080
DISPLAY INTERFACE HDMI 1.4 x 1, up to 3840 x 2160 @30Hz
DP 1.2 x 1, up to 3840 x 2160 @144Hz
MULTIPLE DISPLAY Up to 3 Simultaneous Displays
AUDIO
CODEC Realtek ALC897
AUDIO INTERFACE Line-In / Line-Out / MIC
SPEAKER 5W Speaker
EXTERNAL I/O
ETHERNET I226V 2.5GbE x 2
USB USB 3.2 Gen 2 x 2
SERIAL PORT COM 1, COM 2 (RS-232/422/485, support 5V/12V/RI)
VIDEO HDMI 1.4 x 1
DP 1.2 x 1
INTERNAL I/O
USB USB 2.0 x 4
SERIAL PORT COM 3, COM 4, COM 5, COM 6 (RS-232, support RI only)
VIDEO LVDS x 1
Inverter x 1 (5V/12V@2A)
SATA SATA 6.0Gbps x 1(Default)
AUDIO Audio Header x 1
DIO/GPIO GPIO 16-bits
SMBUS/I2C SMBus / I2C (Default : SMBus)
TOUCH
FAN 4 Pin Smart Fan
SIM Nano SIM x 1
FRONT I/O PANEL Power Button, Reset Button, Power LED, SATA LED, Buzzer
EXPANSION
MINI PCI-E/MSATA Full Sized mPCIe x 1
Full Sized mSATA x 1
M.2 M.2 2242 B-Key x 1 (PCIe 2.0 [x1] + USB 2.0)
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE 32°F ~ 140°F (0°C ~ 60°C)
STORAGE TEMPERATURE -40°F ~ 185°F (-40°C ~ 85°C)
OPERATING HUMIDITY 0% ~ 90% relative humidity, non-condensing
MTBF (HOURS) 364,565
EMC CE/FCC Class A
  • EPIC-ADN9 x 1
  • Screw kit x 1



Optional Accessories
ITEM DESCRIPTION (*Cooler or heatsink is not included in the packing list.)

Heatsink

Please click HERE if you'd like to add the cooler to your order.
