de next-V2K8

86mm x 55mm Single Board with AMD Ryzen™ Embedded V2000 Series Processors
As low as US$1,150.00
Availability: In stock
Inventory: please select an item
SKU
de next-V2K8

  • Onboard AMD Ryzen™ Embedded V2718/V2516 Processor
  • Onboard LPDDR4x 3200MHz, default with 16GB
  • HDMI 1.4b x 1, eDP x 1
  • 2.5GbE x 1, GbE x 1
  • USB 3.2 Gen 2 x 2, USB 2.0 x 4
  • M.2 2280 M-Key x 1 (PCIe [x2]), FPC (PCIe [x4] x 1)
  • COM Port x 2, DIO 8-bit, SATA III x 1
  • 12V-In

Note: To achieve the best performance, it is recommended that you order the CPU Cooler together with the de next.

AMD Ryzen™ Embedded V2000 Series Processors

Powered by the AMD Ryzen™ Embedded V2718 and V2516 processors, the de next-V2K8 boasts an astonishing 8 cores and 16 threads alongside Zen 2 x86 core architecture and 7nm process technology in an unprecedentedly small board. Taking advantage of this strong base, the de next-V2K8 has the high-performance computing performance for edge AI applications along with the mobility for deployment in robotics solutions.

Two Simultaneous Displays with Radeon™ Graphics

Configured to make the most of its integrated AMD Radeon™ Graphics, the de next-V2K8 is designed with utility and sophistication in mind. Hosting eDP and HDMI 1.4b ports for 4K @30Hz, the de next-V2K8 can produce two simultaneous displays. In addition to this, its 2.5 GbE port, dual RS232/422/485 pin headers, and total of six USB ensure connectivity with a broad range of peripheral cameras and sensors.

Versatile Deployment for any Vertical Market

The de next-V2K8’s miniature form factor, exceptional processing power, and light weight ensure it is suitable for a wealth of vertical market environments in which utility in deployment is paramount, including drone and smart transport solutions. Armed with 16GB of onboard LPDDR4x and high-speed I/O features capable of channeling its industrial-grade power, the de next-V2K8 provides customers with both speed and performance in a board small enough for even the most restrictive deployment spaces.

DENEXT-V2K8-A11-0002
SYSTEM
FORM FACTOR 86mm x 55mm, Single Board Computer
CPU AMD Ryzen™ Embedded V2516 with Radeon™ Graphics (6C/16T, 2.1GHz, 25W)
CHIPSET Integrated with AMD SoC
MEMORY TYPE Onboard LPDDR4x 3200, default with 16GB
BIOS UEFI
WAKE ON LAN Yes
WATCHDOG TIMER 255 Levels
SECURITY fTPM
RTC Battery Lithium Battery 3V/240mAh
DIMENSION (L X W) 3.38” x 2.17” (86mm x 55mm)
OS SUPPORT Windows 10 (64bit)
Ubuntu 22.04 (kernel 5.15)
POWER
POWER REQUIREMENT +12V
POWER SUPPLY TYPE AT/ATX
CONNECTOR DC Jack Connector
POWER CONSUMPTION V2718 , LPDDR4 16GB, 3.07A @12V, 36.84W (TYPICAL)
V2718 , LPDDR4 16GB, 3.92A @12V, 47.04W (MAX)
DISPLAY
CONTROLLER AMD V-Series V2000 with Radeon™ Graphics
LVDS/eDP eDP 1.4 x 1 , up to 3840 x 2160
DISPLAY INTERFACE HDMI 1.4 x 1 , up to 3840 x 2160@30Hz
Multiple Display 2 Simultaneous Displays
EXTERNAL I/O
ETHERNET Realtek RTL8111, 1GbE RJ-45 x 1
Intel® i226, 2.5GbE RJ-45 x 1
USB USB 3.2 Gen 2 x 2
VIDEO HDMI 1.4b x 1
INTERNAL I/O
USB USB 2.0 x 4
Note : USB2.0 x 2 shared with adapter card PER-T642 / PER-T643. (de next-V2K8-A11 only)
SERIAL PORT COM1 , COM2 (RS232/422/485, support 5V/RI)
VIDEO eDP 1.4 x 1
SATA SATA 6.0 Gbps x 1
with +5V SATA Power Connector x 1
DIO/GPIO GPIO 8 bits
SMBus/I2C Optional
FAN 4 Pin Smart Fan
Front Panel Power Button, Reset Button, Power LED, SATA LED, Buzzer
EXPANSION
M.2 M.2 2280 M-key x 1 (PCIe[x2] x 1 or PCIe[x1] x 2, selected by BIOS)
OTHERS FPC Connector x 1 (PCIe 3.0 [x4] x 1)
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE 32°F ~ 140°F (0°C ~ 60°C)
STORAGE TEMPERATURE -40°F ~ 176°F (-40°C ~ 80°C)
OPERATING HUMIDITY 0% ~ 90% relative humidity, non-condensing
MTBF (HOURS) 609,263
CERTIFICATION CE/FCC Class A
DENEXT-V2K8-A11-0001
SYSTEM
FORM FACTOR 86mm x 55mm, Single Board Computer
CPU AMD Ryzen™ Embedded V2718 with Radeon™ Graphics (8C/16T, 1.7GHz, 25W)
CHIPSET Integrated with AMD SoC
MEMORY TYPE Onboard LPDDR4x 3200, default with 16GB
BIOS UEFI
WAKE ON LAN Yes
WATCHDOG TIMER 255 Levels
SECURITY fTPM
RTC Battery Lithium Battery 3V/240mAh
DIMENSION (L X W) 3.38” x 2.17” (86mm x 55mm)
OS SUPPORT Windows 10 (64bit)
Ubuntu 22.04 (kernel 5.15)
POWER
POWER REQUIREMENT +12V
POWER SUPPLY TYPE AT/ATX
CONNECTOR DC Jack Connector
POWER CONSUMPTION V2718 , LPDDR4 16GB, 3.07A @12V, 36.84W (TYPICAL)
V2718 , LPDDR4 16GB, 3.92A @12V, 47.04W (MAX)
DISPLAY
CONTROLLER AMD V-Series V2000 with Radeon™ Graphics
LVDS/eDP eDP 1.4 x 1 , up to 3840 x 2160
DISPLAY INTERFACE HDMI 1.4 x 1 , up to 3840 x 2160@30Hz
Multiple Display 2 Simultaneous Displays
EXTERNAL I/O
ETHERNET Realtek RTL8111, 1GbE RJ-45 x 1
Intel® i226, 2.5GbE RJ-45 x 1
USB USB 3.2 Gen 2 x 2
VIDEO HDMI 1.4b x 1
INTERNAL I/O
USB USB 2.0 x 4
Note : USB2.0 x 2 shared with adapter card PER-T642 / PER-T643. (de next-V2K8-A11 only)
SERIAL PORT COM1 , COM2 (RS232/422/485, support 5V/RI)
VIDEO eDP 1.4 x 1
SATA SATA 6.0 Gbps x 1
with +5V SATA Power Connector x 1
DIO/GPIO GPIO 8 bits
SMBus/I2C Optional
FAN 4 Pin Smart Fan
Front Panel Power Button, Reset Button, Power LED, SATA LED, Buzzer
EXPANSION
M.2 M.2 2280 M-key x 1 (PCIe[x2] x 1 or PCIe[x1] x 2, selected by BIOS)
OTHERS FPC Connector x 1 (PCIe 3.0 [x4] x 1)
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE 32°F ~ 140°F (0°C ~ 60°C)
STORAGE TEMPERATURE -40°F ~ 176°F (-40°C ~ 80°C)
OPERATING HUMIDITY 0% ~ 90% relative humidity, non-condensing
MTBF (HOURS) 609,263
CERTIFICATION CE/FCC Class A
DENEXT-V2K8-A11-0003

*【Pre-Order】Scheduled to be Dispached on Apr 19

SYSTEM
FORM FACTOR 86mm x 55mm, Single Board Computer
CPU AMD Ryzen™ Embedded V2718 with Radeon™ Graphics (8C/16T, 1.7GHz, 25W)
CHIPSET Integrated with AMD SoC
MEMORY TYPE Onboard LPDDR4x 3200, default with 16GB
BIOS UEFI
WAKE ON LAN Yes
WATCHDOG TIMER 255 Levels
SECURITY fTPM
RTC Battery Lithium Battery 3V/240mAh
DIMENSION (L X W) 3.38” x 2.17” (86mm x 55mm)
OS SUPPORT Windows 10 (64bit)
Ubuntu 22.04 (kernel 5.15)
POWER
POWER REQUIREMENT +12V
POWER SUPPLY TYPE AT/ATX
CONNECTOR Phoenix 2-Pin Connector
POWER CONSUMPTION V2718 , LPDDR4 16GB, 3.07A @12V, 36.84W (TYPICAL)
V2718 , LPDDR4 16GB, 3.92A @12V, 47.04W (MAX)
DISPLAY
CONTROLLER AMD V-Series V2000 with Radeon™ Graphics
LVDS/eDP eDP 1.4 x 1 , up to 3840 x 2160
DISPLAY INTERFACE HDMI 1.4 x 1 , up to 3840 x 2160@30Hz
Multiple Display 2 Simultaneous Displays
EXTERNAL I/O
ETHERNET Realtek RTL8111, 1GbE RJ-45 x 1
Intel® i226, 2.5GbE RJ-45 x 1
USB USB 3.2 Gen 2 x 2
VIDEO HDMI 1.4b x 1
INTERNAL I/O
USB USB 2.0 x 4
Note : USB2.0 x 2 shared with adapter card PER-T642 / PER-T643. (de next-V2K8-A11 only)
SERIAL PORT COM1 , COM2 (RS232/422/485, support 5V/RI)
VIDEO eDP 1.4 x 1
SATA SATA 6.0 Gbps x 1
with +5V SATA Power Connector x 1
DIO/GPIO GPIO 8 bits
SMBus/I2C Optional
FAN 4 Pin Smart Fan
Front Panel Power Button, Reset Button, Power LED, SATA LED, Buzzer
EXPANSION
M.2 M.2 2280 M-key x 1 (PCIe[x2] x 1 or PCIe[x1] x 2, selected by BIOS)
OTHERS FPC Connector x 1 (PCIe 3.0 [x4] x 1)
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE 32°F ~ 140°F (0°C ~ 60°C)
STORAGE TEMPERATURE -40°F ~ 176°F (-40°C ~ 80°C)
OPERATING HUMIDITY 0% ~ 90% relative humidity, non-condensing
MTBF (HOURS) 609,263
CERTIFICATION CE/FCC Class A
DENEXT-V2K8-A10-0001
SYSTEM
FORM FACTOR 86mm x 55mm, Single board computer
CPU AMD Ryzen™ Embedded V2718 with Radeon™ Graphics (8C/16T, 1.7GHz, 25W)
CHIPSET Integrated with AMD SoC
MEMORY TYPE Onboard LPDDR4x 3200 , up to 16GB
BIOS UEFI
WAKE ON LAN Yes
WATCHDOG TIMER 255 Levels
SECURITY fTPM
RTC Battery Lithium Battery 3V/240mAh
DIMENSION (L X W) 3.38” x 2.17” (86 mm x 55 mm)
OS SUPPORT Windows 10 (64bit)
Ubuntu 22.04 (kernel 5.15)
POWER
POWER REQUIREMENT +12V
POWER SUPPLY TYPE AT/ATX
CONNECTOR DC Jack
POWER CONSUMPTION V2718 , LPDDR4 16GB, 3.07A @12V, 36.84W (TYPICAL)
V2718 , LPDDR4 16GB, 3.92A @12V, 47.04W (MAX)
DISPLAY
CONTROLLER AMD V-Series V2000 with Radeon™ Graphics
LVDS/eDP eDP 1.4 x 1 , up to 3840 x 2160
DISPLAY INTERFACE HDMI 1.4 x 1 , up to 3840 x 2160@30Hz
Multiple Display Up to 2 Simultaneous Displays
EXTERNAL I/O
ETHERNET Realtek RTL8111, 1GbE RJ-45 x 1
Intel® i225LM, 10/100/2500Base, RJ-45 x 1
USB USB3.2 Gen 2 x 2
VIDEO HDMI 1.4b x 1
INTERNAL I/O
USB USB2.0 x 4 (via pin header)
SERIAL PORT COM1 , COM2 (RS232/422/485, support 5V/RI)
VIDEO eDP x 1
SATA SATA 6.0 Gbps x 1
with +5V SATA Power Connector x 1
DIO/GPIO GPIO 8 bits
SMBus/I2C Optional
FAN 4 Pin Smart Fan
Front Panel Power Button, Reset Button, Power LED, SATA LED, Buzzer
EXPANSION
M.2 M.2 2280 M-Key x 1 (PCIe [x2])
OTHERS FPC Connector x 1 (PCIe 3.0 [x4] x 1)
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE 32°F~ 140°F (0°C ~ 60°C)
STORAGE TEMPERATURE -40°F ~ 176°F (-40°C ~ 80°C)
OPERATING HUMIDITY 0% ~ 90% relative humidity, non-condensing
MTBF (HOURS) 609,263
CERTIFICATION CE/FCC Class A
  • de next-V2K8 x 1
  • Copper Stud.M2.5 x 4



Optional Accessories
Item DESCRIPTION

CPU Cooler

Cooler or heatsink is not included in the packing list.
Please click HERE if you'd like to add the cooler to your order.

Easy bracket

The bracket makes the assembly of the de next MB and CPU cooler much easier.
Please click HERE if you'd like to add it to your order.
