MIPICSI Camera RPI Converter Kit
MIPI-CSI Camera RPI Converter Kit (for UP Squared Pro 7000/UP Squared i12/UP Xtreme i12/UP Xtreme i14/UP Squared Pro 710H)
US$38.00
Availability:
Pre-Order
Only 2 left
SKU
UPCR-CAMB-A10-0002
【Pre-Order】 Ready on MAR 04
- 4-Lane + Clock from Camera Module Connector x 2
- 5V/2A Power-In from Wafer
Boost performance with the UP RPI Converter Kit (for MIPI cameras on UP Squared Pro 7000, UP Squared i12, UP Xtreme i12, UP Xtreme i14, and UP Squared Pro 710H).
| SYSTEM | |
| I/O | Power: 5V/2A In from Wafer MIPI-CSI In: 4-Lane + Clock from Camera Module Connector x 2 MIPI-CSI Out: 61-pin FPC Connector x 1 |
| Dimension | 3.3" x 2.4" (85mm x 61mm) |
| Net Weight | 0.1 lb. (0.04Kg) |
| Gross Weight | 0.13 lb. (0.06Kg) |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C), 0.5m/s airflow |
| Operation Humidity | 10% ~90% relative humidity, non-condensing |
- Converter board
- FPC Cable
- Power Cable
- Screws/Stud Pack
