PICO-MTU4

Pico-ITX Board with Intel® Core™ Ultra 5 Processor 125U
As low as US$891.67
Availability: In stock
Inventory: please select an item
SKU
PICO-MTU4

  • Intel® Core™ Ultra 5 Processor SoC
  • Onboard LPDDR5, up to 32GB
  • 2.5GbE + 1GbE
  • HDMI 1.4 + eDP 1.4
  • M.2 2280 M-Key x 1 (PCIe 4.0 [x4]/SATA)
  • M.2 2230 E-Key x 1 (PCIe 4.0 [x1] + USB 2.0)
  • USB 3.2 Gen 2 x 2 ports + USB 2.0 x 2
  • RS-232/422/485 x 2
  • TPM, GPIO 4-bit, SATA 6.0 Gb/s x 1
  • SMBus/I2C (Default SMBus)

Miniature Size, Meteoric Performance

As the world's smallest board equipped with the new Intel® Core™ Ultra platform, the PICO-MTU4 leverages the disaggregated die design's hybrid CPU core architecture and dedicated AI engine NPU to achieve up to a 24% boost in multi-thread performance and 50% lower SoC power consumption. On a compact 2.5" form factor, this combination makes the PICO-MTU4 a miniature dynamo capable of powering even the most advanced edge computing, smart healthcare, and industrial robotics solutions.

Refined Mechanical Design

Through optimized component placement and a dedicated heatsink, the PICO-MTU4 boasts a remarkable temperature tolerance of -20°C to 70°C. Furthermore, the board's advanced image rendering, high AI workload throughput, and Wi-Fi 6 support add credibility to the PICO-MTU4's potential as the central component in roadside unit solutions, where real-time data processing and streamlined AI workload management are crucial.

High-Bandwidth Communication

Complementing the PICO-MTU4's power is its high-bandwidth LPDDR5x system memory and diverse interface selection. Dual LAN and USB 3.2 Gen 2 ports can accommodate a range of cameras and sensors, while the board's internal connectors offer a variety of serial interfaces for industrial protocols, such as dual COM for RS-232/422/485, a 4-bit GPIO, and SMBus. This configuration makes the PICO-MTU4 the ideal foundation for SCADA, MES, and system monitoring devices.

PICO-MTU4-A10-0001
SYSTEM
FORM FACTOR PICO-ITX
CPU Intel® Core™ Ultra 5 Processor 125U (2PC+10EC/14T, P-core 1.30 GHz, E-core 0.80 GHz, 15W)
CHIPSET Integrated with Intel® SoC
MEMORY TYPE Single-Channel LPDDR5 6400, default with 8GB
BIOS UEFI
WAKE ON LAN Yes
WATCHDOG TIMER 255 Levels
Security TPM 2.0
RTC Battery Lithium Battery 3V/240mAh
DIMENSION 3.94" x 2.84" (100mm x 72mm)
Gross Weight 0.18 lbs. (0.08 kg)
OS Support Windows 10/11 (64bit)
Linux Ubuntu 22.04.2 kernel 5.19.0 32 generic
POWER
POWER REQUIREMENT +12V
POWER SUPPLY TYPE AT/ATX
CONNECTOR Phoenix 2-pin Connector (Default)
Lockable DC Jack Connector (Optional)
POWER CONSUMPTION Intel® Core™ Ultra 7 Processor 165U, DDR5 32GB x1, 2.94A@+12V (Typical)
Intel® Core™ Ultra 7 Processor 165U, DDR5 32GB x1, 5.13A@+12V (Max)
DISPLAY
CONTROLLER Intel® Graphics
LVDS/eDP eDP 1.4 x 1
Display Interface HDMI 1.4 x 1, 3840 x 2160 @30Hz
Multiple Display Up to 2 Simultaneous Displays
AUDIO
CODEC
AUDIO INTERFACE
EXTERNAL I/O
ETHERNET Intel® Ethernet Controller I226 2.5GbE, RJ-45 x 1
Intel® Ethernet Connection I219, 1GbE, RJ-45 x 1
USB USB 3.2 Gen 2 x 2 ports
VIDEO HDMI 1.4 x 1
INTERNAL I/O
USB USB 2.0 x 2
SERIAL PORT COM 1 ~ 2 (RS-232/422/485, supports 5V/12V/RI)
VIDEO
SATA SATA 6Gb/s x 1
+5V SATA Power Connector x 1
AUDIO
DIO/GPIO GPIO 4-bit
SMBus/I2C I2C/SMBus (Default: SMBus)
FAN 4pins Smart Fan x1
Front Panel HDD LED, PWR LED, Power Button, Buzzer, Reset
EXPANSION
MINI PCI-E/MSATA
M.2 M.2 2280 M-Key x 1 (PCIe 4.0 [x4] / SATA, Default: PCIe [x4], select by BOM)
M.2 2230 E-Key x 1 (PCIe 4.0 [x1] + USB 2.0)
Others
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE -4°F ~ 158°F (-20°C ~ 70°C)
STORAGE TEMPERATURE -40°F ~ 185°F (-40°C ~ 85°C)
OPERATING HUMIDITY 0% ~ 90% relative humidity, non-condensing
MTBF (HOURS) 1,063,716
EMC CE/FCC Class A
PICO-MTU4-A10-0002
SYSTEM
FORM FACTOR PICO-ITX
CPU Intel® Core™ Ultra 5 Processor 125U (2PC+10EC/14T, P-core 1.30 GHz, E-core 0.80 GHz, 15W)
CHIPSET Integrated with Intel® SoC
MEMORY TYPE Single-Channel LPDDR5 6400, default with 16GB
BIOS UEFI
WAKE ON LAN Yes
WATCHDOG TIMER 255 Levels
Security TPM 2.0
RTC Battery Lithium Battery 3V/240mAh
DIMENSION 3.94" x 2.84" (100mm x 72mm)
Gross Weight 0.18 lbs. (0.08 kg)
OS Support Windows 10/11 (64bit)
Linux Ubuntu 22.04.2 kernel 5.19.0 32 generic
POWER
POWER REQUIREMENT +12V
POWER SUPPLY TYPE AT/ATX
CONNECTOR Phoenix 2-pin Connector (Default)
Lockable DC Jack Connector (Optional)
POWER CONSUMPTION Intel® Core™ Ultra 7 Processor 165U, DDR5 32GB x1, 2.94A@+12V (Typical)
Intel® Core™ Ultra 7 Processor 165U, DDR5 32GB x1, 5.13A@+12V (Max)
DISPLAY
CONTROLLER Intel® Graphics
LVDS/eDP eDP 1.4 x 1
Display Interface HDMI 1.4 x 1, 3840 x 2160 @30Hz
Multiple Display Up to 2 Simultaneous Displays
AUDIO
CODEC
AUDIO INTERFACE
EXTERNAL I/O
ETHERNET Intel® Ethernet Controller I226 2.5GbE, RJ-45 x 1
Intel® Ethernet Connection I219, 1GbE, RJ-45 x 1
USB USB 3.2 Gen 2 x 2 ports
VIDEO HDMI 1.4 x 1
INTERNAL I/O
USB USB 2.0 x 2
SERIAL PORT COM 1 ~ 2 (RS-232/422/485, supports 5V/12V/RI)
VIDEO
SATA SATA 6Gb/s x 1
+5V SATA Power Connector x 1
AUDIO
DIO/GPIO GPIO 4-bit
SMBus/I2C I2C/SMBus (Default: SMBus)
FAN 4pins Smart Fan x1
Front Panel HDD LED, PWR LED, Power Button, Buzzer, Reset
EXPANSION
MINI PCI-E/MSATA
M.2 M.2 2280 M-Key x 1 (PCIe 4.0 [x4] / SATA, Default: PCIe [x4], select by BOM)
M.2 2230 E-Key x 1 (PCIe 4.0 [x1] + USB 2.0)
Others
ENVIRONMENT & CERTIFICATION
OPERATING TEMPERATURE -4°F ~ 158°F (-20°C ~ 70°C)
STORAGE TEMPERATURE -40°F ~ 185°F (-40°C ~ 85°C)
OPERATING HUMIDITY 0% ~ 90% relative humidity, non-condensing
MTBF (HOURS) 1,063,716
EMC CE/FCC Class A
  • PICO-MTU4



Optional Accessories
Item DESCRIPTION

Cooler

Cooler or heatsink is not included in the packing list.
Please click HERE if you'd like to add it to your order.

Power Supply Module

Cooler or heatsink is not included in the packing list.
Please click HERE if you'd like to add it to your order.
