MAXER-2100

AI Inference Server, 2U Rackmount, 12/13th Gen CPU, RTX-4080 Super
US$4,242.00
Availability: In stock
Only 2 left
SKU
MAXER-2100-Q670-A1-1010

  • High-perfomance for AI inference: Support NVIDIA RTX 4090, RTX 4080 Super etc.
  • 12/13th Gen Intel® Core™ LGA1700 Socket Processors
  • High CPU computing performance: Build in i9-13900, up to i9-13900K supported
  • 2U Rack Mount, Front Access I/O Design
  • M.2 2242/2280 M-Key x 2
  • M.2 3042/3052/2242 B-Key + Micro SIM Slot
  • M.2 2230 E-Key x 1
  • Onboard TPM 2.0

Automated Optical Inspection Made Easy

AAEON's new MAXER-2100 is the superior choice when selecting an edge server to run complex AI inferencing software. Because of its support for both 12th and 13th Generation Intel® Core™ processors, multiple NVIDIA® GPU cards, and its deep learning capabilities, the MAXER-2100 was deployed as an edge server alongside an AOI device as part of a broader quality inspection solution, running the company’s AI inferencing model to quickly and accurately detect defects during the manufacturing process.

>99% Accuracy

The MAXER-2100 utilized multiple GPUs to accelerate AI inferencing performance, resulting in the identification of component defects over 99% of the time.

Accelerated Defect Detection

The MAXER-2100 reduced the time needed for defect analysis from between 2 and 3s per photograph via manual inspection to just 0.05s per photograph.

Reduction in Labor Costs

The MAXER-2100 reduced reliance on human resources by 67% through the removal of elementary inspection tasks from employee duties.

The AI Inference Server Solution to Enhance AI-Assisted Quality Inspection

The MAXER-2100 is a 2U Rackmount Controller specifically crafted to serve as an inference server for solutions demanding the utmost precision. Engineered to fine-tune AI models and execute intricate AI algorithms for AOI in chip and PCBA manufacturing, the MAXER-2100 is compact, expandable, and signifies a novel approach to enhancing industrial computing capabilities.

System
CPU 12/13th Generation Intel® Core™ LGA1700 Socket Processors, TDP Max 125W
Build in: i9-13900
GPU GeForce RTX 4080 SUPER (Optional support NVIDIA GeForce Graphic or AI computing card)
Chipset Intel Q670
System Memory DDR5 4000MHz DIMM x 4, Up to 128GB
Non-ECC, Un-buffered Memory, Dual-Channel Memory Architecture
Display Interface HDMI 2.0 x 1, DP 1.4 x 1, VGA x1
Storage Device 2.5" SATA-III Drive Bay x 2 (Swappable, RAID 0/1)
M.2 2280 M key for NVMe SSD x 1
Ethernet RJ-45 GbE LAN x 1 (supports Intel® AMT 12.0)
RJ-45 GbE LAN x 1
RJ-45 2.5GbE LAN x 2
USB USB 3.2 Gen2 x 4 (10Gbps)
Serial Port DB-9 x 1 for RS-232/422/485
Audio Audio (Mic-in/Line-out/Line-In)
Expansion PCIe [x16] x 1 for RTX 4080 Super
M.2 3042/3052 B-Key x 1 + MicroSIM Slot
M.2 2230 E-Key x 1
TPM TPM 2.0 Onbaord
Indicator System LED x 1, HDD Activity x 1
OS support Windows® 10 IoT Enterprise 64-bit
Windows® 11 PRO 64-bit
Ubuntu 22.04.3 and above
Drive Bay 2.5" SATA-III Drive Bay x 2 (Swappable, RAID 0/1)
Front Control Power On/Off, System Reset
Power Supply
Power Requirement Build in 1000W power supply
Mechanical
Mounting Rack Mount
Dimensions (W x H x D) 17" x 3.46" x 17.6" (431.8mm x 88mm x 448mm)
Gross Weight 31.52 lb (14.3kg)
Net Weight 24.25 lb (11kg)
Environmental
Operating Temperature 32°F ~ 104°F (0°C ~ 40°C), according to IEC68-2 with 0.5 m/s AirFlow
Storage Temperature -40˚F ~ 176˚F (-40˚C ~ 80˚C)
Storage Humidity 5 ~ 95% @ 40˚C, non-condensing
Certification CE/FCC class A
  • MAXER-2100



Optional Accessories
Item DESCRIPTION

Power Cord

Power cord varies from countries and needs to be purchased separately.
Please click below link if you'd like to add the power cord to your order as well.
- US/ Taiwan Type
- Europe Type
- Japan Type

Wireless Module

- M.2 2230 EKey
