MIX-EHLD1
Mini-ITX with Intel® Atom x6413E /Celeron J6412 processors , Max. 12W TDPs, Flexible rear IO, 12V DC input
As low as
US$211.00
Availability:
In stock
Inventory: please select an item
SKU
MIX-EHLD1
AAEON had expanded its mini-ITX product lineup with MIX-EHLD1, a mini-ITX thin motherboard powered by Intel® Atom® x6413E/Celeron® J6412 processor (formerly Elkhart Lake) to boost edge computing and IoT performance. Designed as the pioneering processors for IoT enhancement, these processors offer nearly 2x upgrades in single thread, multi-thread, and graphical performances than its predecessor to accelerate real-world edge computing and IoT deployments. In addition, these IoT-centric processors are built in with Intel® Programmable Service Engine (PSE), an efficient offload engine that can reduce the workloads for CPU cores and enable industrial control functions in IoT applications. For expansion purpose, MIX-EHLD1 provides two M.2 slots and one mini-card socket for wireless connectivity, storage, or AI-optimization modules. As IoT applications today require intensive visual presentation, MIX-EHLD1 supports 3 display outputs. Regarding connections with multiple peripheral devices, MIX-EHLD1 comes with two USB3.2 Gen1 ports and four USB2.0 ports.
MIX-EHLD1-A11-J6412
| SYSTEM | |
| PROCESSOR | Intel Elkhart Lake Processor, Max. 12W TDPs Celeron J6412 |
| MEMORY | SO-DIMM, max. 32GB , DDR4 3200MTS x 2 |
| I/O CHIPSET | NCT6126D |
| ETHERNET | RTL8111H x 2 |
| AUDIO | Realtek® ALC897 |
| TPM | Nuvoton NPCT750 TPM2.0 onboard |
| EXPANSION SLOT | M.2 Slot (B key; 3042/3052) x1 mini-PCIe(Full/Half) ) x 1 SIM socket x 1(default for B-key) |
| BIOS | 256Mbit Flash ROM, AMI BIOS |
| H/W MONITOR | Temperature Monitor on CPU/Chassis, Voltage Monitor on Vcore/5V/12V, Fan Monitor on Chassis |
| WATCHDOG TIMER | 1~255 step by software program |
| SMART FAN CONTROL | Chassis Fan |
| WAKE ON LAN/ PXE | Yes (WOL / PXE) |
| POWER STATE | S3, S4, S5 |
| GRAPHICS | |
| GRAPHICS CHIPSET | Intel® UHD Graphics |
| GRAPHICS MULTI DISPLAY | 3 Independent Display(1xVGA+1x HDMI + 1x LVDS/eDP) |
| VGA | Up to 1920 x 1200 @60 Hz |
| DVI | — |
| HDMI | Up to 4096 x 2160 @ 60Hz |
| DISPLAYPORT | — |
| LVDS | Up to 1920 x 1080 @60Hz, Dual Channel 18/24 bit (via CH7513) co-layout eDP (default LVDS) |
| EDP | Up to 3840 x 2160 @ 30Hz |
| BACKLIGHT CONTROL | Voltage / PWM, use HW control |
| ENVIRONMENTAL & POWER & ME | |
| BATTERY | Lithium battery |
| POWER REQUIREMENT | 12(+/-5%) DC |
| OPERATING TEMPERATURE | 32°F ~ 140°F(0 ~ 60°C) (Operational humidity: 60°C @ 90% RH Non-Condensing) |
| STORAGE TEMPERATURE | — |
| CERTIFICATION | CE & FCC Class A |
| FORM FACTOR | Mini-ITX: 6.7" x 6.7" (170mm x 170mm) |
| WEIGHT | 1.1 lb (0.5 Kg) |
| MTBF (HOURS) | — |
| REAR I/O PORTS | |
| USB | USB 3.2(Gne1) ports x 2 USB 2.0 ports x 4 (upper 2 ports by BOM Optional) |
| DISPLAY I/O | HDMI x 1, VGA x 1 |
| AUDIO I/O | Mic-in x 1, Line out x 1 |
| LAN I/O | 1GbE x 2 |
| SERIAL PORT | RS232 by BOM Optional |
| OTHERS | DC Jack x 1 |
| INTERNAL I/O CONNECTORS | |
| STORAGE | M.2 Slot (M key; 2280;PCIex2) SATA 6Gb/s x 1 SATA power connector (5V / 12V @1A) x 1 |
| USB | USB2.0 ports x 2 |
| DISPLAY I/O | 40-pin LVDS / eDP connector x 1 |
| AUDIO I/O | AAFP follow ASUS pin out x 1 |
| SERIAL PORT | Box header x 5 for COM (COM1: RS-232/422/485 supports 5V/12V/RI; COM2~6: RS-232) |
| DIO | Digital I/O box header x 1 |
| FAN | 4-pin Chassis Fan connector x 1 |
| OTHERS | Front Panel connector x 1, Chassis Intrusion x 1, Buzzer onboard x 1, Clear CMOS jumper x 1, AT/ATX mode select jumper x 1 |
| OS | |
| OS SUPPORT | Windows® 10 64-bit, Linux Ubuntu 64 bit (20.04.2/Kernel 5.4) |
MIX-EHLD1-A10-X6413
| SYSTEM | |
| PROCESSOR | Intel Elkhart Lake Processor Max. 12W TDPs, Atom X6413E |
| MEMORY | SO-DIMM, max. 32GB , DDR4 3200MTS x 2 |
| I/O CHIPSET | NCT6126D |
| ETHERNET | RTL8111H x 2 |
| AUDIO | Realtek® ALC897 |
| TPM | Nuvoton NPCT750 TPM2.0 onboard |
| EXPANSION SLOT | M.2 Slot (B key; 3042/3052) x1 mini-PCIe(Full/Half) ) x 1 SIM socket x 1(default for B-key) |
| BIOS | 256Mbit Flash ROM, AMI BIOS |
| H/W MONITOR | Temperature Monitor on CPU/Chassis, Voltage Monitor on Vcore/5V/12V, Fan Monitor on Chassis |
| WATCHDOG TIMER | 1~255 step by software program |
| SMART FAN CONTROL | Chassis Fan |
| WAKE ON LAN/ PXE | Yes (WOL / PXE) |
| POWER STATE | S3, S4, S5 |
| GRAPHICS | |
| GRAPHICS CHIPSET | Intel® UHD Graphics |
| GRAPHICS MULTI DISPLAY | 3 Independent Display(1xVGA+1x HDMI + 1x LVDS/eDP) |
| VGA | Up to 1920 x 1200 @60 Hz |
| DVI | — |
| HDMI | Up to 4096 x 2160 @ 60Hz |
| DISPLAYPORT | — |
| LVDS | Up to 1920 x 1080 @60Hz, Dual Channel 18/24 bit (via CH7513) co-layout eDP (default LVDS) |
| EDP | Up to 3840 x 2160 @ 30Hz |
| BACKLIGHT CONTROL | Voltage / PWM, use HW control |
| ENVIRONMENTAL & POWER & ME | |
| BATTERY | Lithium battery |
| POWER REQUIREMENT | 12(+/-5%) DC |
| OPERATING TEMPERATURE | 32°F ~ 140°F(0 ~ 60°C) (Operational humidity: 60°C @ 90% RH Non-Condensing) |
| STORAGE TEMPERATURE | — |
| CERTIFICATION | CE & FCC Class A |
| FORM FACTOR | Mini-ITX: 6.7" x 6.7" (170mm x 170mm) |
| WEIGHT | 1.1 lb (0.5 Kg) |
| MTBF (HOURS) | — |
| REAR I/O PORTS | |
| USB | USB 3.2(Gne1) ports x 2 USB 2.0 ports x 4 (upper 2 ports by BOM Optional) |
| DISPLAY I/O | HDMI x 1, VGA x 1 |
| AUDIO I/O | Mic-in x 1, Line out x 1 |
| LAN I/O | 1GbE x 2 |
| SERIAL PORT | RS232 by BOM Optional |
| OTHERS | DC Jack x 1 |
| INTERNAL I/O CONNECTORS | |
| STORAGE | M.2 Slot (M key; 2280;PCIex2) SATA 6Gb/s x 1 SATA power connector (5V / 12V @1A) x 1 |
| USB | USB2.0 ports x 2 |
| DISPLAY I/O | 40-pin LVDS / eDP connector x 1 |
| AUDIO I/O | AAFP follow ASUS pin out x 1 |
| SERIAL PORT | Box header x 5 for COM (COM1: RS-232/422/485 supports 5V/12V/RI; COM2~6: RS-232) |
| DIO | Digital I/O box header x 1 |
| FAN | 4-pin Chassis Fan connector x 1 |
| OTHERS | Front Panel connector x 1, Chassis Intrusion x 1, Buzzer onboard x 1, Clear CMOS jumper x 1, AT/ATX mode select jumper x 1 |
| OS | |
| OS SUPPORT | Windows® 10 64-bit, Linux Ubuntu 64 bit (20.04.2/Kernel 5.4) |
- SATA Cable
- I/O Shield
- MIX-EHLD1
