BOXER-6406U-ADN

Fanless Compact Embedded Computer with Intel Atom® x7211E and Intel® Processor N-series Processors

As low as US$416.00

Availability: In stock

Inventory: please select an item

SKU

BOXER-6406U-ADN

Intel Atom® x7211E and Intel® Processor N-series Processors
DDR5 4800MHz via SODIMM
2.5GbE x 2
M.2 2280 M-Key x 1, M.2 2230 E-Key x 1
USB 3.2 Gen 2 (Type-A) x 2
Onboard TPM 2.0
Wide -20°C ~ 60°C Operating Temperature
Compact Size

Note: This product is available as a barebone kit on AAEON eShop. If you would like to order additional components for a more complete system, please contact AAEON sales for more options and assistance.

Price Drop Notification

Qty:

Details

Building on the dominance of the fanless, embedded, industrially robust BOXER-6000 series is the BOXER-6645U-RPL and BOXER-6406U-ADN. The dynamic duo offer multi-platform industrial computing for applications ranging from comprehensive smart factory deployments to low power, efficient AGVs and eGates.

Low power, compact, and robust, the BOXER-6406U-ADN represents the very best in efficient industrial computing. Easy expansion is joined by a plethora of communication interfaces, granting users a platform that performs in tough environments.

Compact Design

Exceptionally compact 164mm x 104.5mm x 47mm chassis design to facilitate easy deployment and integration in tight spaces.

Flexible Expansion

Wi-Fi and cellular communication via M.2 E-Key and SIM slots, along with NVMe and additional storage via Mini Card and M.2 M-Key expansion.

Power-Efficiency

6W Intel® Processor N-series CPUs provide low power operation for robust performance with a smaller energy footprint.

Specification

BOXER-6406U-ADN-A1-1010

SYSTEM
CPU	Intel® Processor N200
CHIPSET	Intel® SoC
SYSTEM MEMORY	(Default: No) DDR5 4800Mhz SODIMM x 1, up to 32GB
DISPLAY INTERFACE	HDMI x 2
STORAGE DEVICE	M.2 2280 M-Key x 1 (PCIe Gen 3 [x2]) 2.5" SATA HDD/SSD x 1
ETHERNET	RJ-45 x 2 for 2.5GbE LAN (Intel® I226-LM)
I/O	HDMI x 2 RJ-45 x 2 for 2.5GbE LAN (Intel® Ethernet Controller I226-LM) USB 3.2 Gen 2 (Type-A) x 2 USB 2.0 (Type-A) x 2 DB-9 x 2 for RS-232/422/485 DB-15 x 1 Male for 8-Channel Digital I/O 12V DC Jack Input Power Button with LED x 1 Antenna Opening
EXPANSION	M.2 2280 M-Key x 1 (PCIe [x2]) M.2 2230 E-Key x 1 Full-Size Mini Card x 1 (PCIe + USB) SIM Slot x 1
INDICATOR	Power Button with LED
OS SUPPORT	Windows® 10 IoT Enterprise Windows® 11 Pro Ubuntu 22.04
POWER SUPPLY
POWER REQUIREMENT	Lockable DC Jack x 1 for 12V DC-in
MECHANICAL
MOUNTING	Wallmount
DIMENSIONS (W X H X D)	6.46" x 4.11" x 1.85" (164mm x 104.5mm x 47mm) without bracket 8.74" x 4.11" x 2.13" (222mm x 104.5mm x 54mm) with bracket
GROSS WEIGHT	3.8 lb. (1.73Kg)
NET WEIGHT	2 lb. (0.93Kg)
ENVIRONMENTAL
OPERATING TEMPERATURE	-4°F ~ 140°F (-20°C ~ 60°C), according to IEC68-2 with 0.7 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM)
STORAGE TEMPERATURE	-40°F ~ 176°F (-40°C ~ 80°C)
STORAGE HUMIDITY	5 ~ 95% @ 40°C, non-condensing
ANTI-VIBRATION	With SSD: Random, 3 Grms, 5~500Hz
ANTI-SHOCK	With SSD: 50 G, IEC 60068-2-27, half sine, 11 ms duration
CERTIFICATION	CE/FCC Class A

BOXER-6406U-ADN-A2-1010

SYSTEM
CPU	Intel® Processor N50
CHIPSET	Intel® SoC
SYSTEM MEMORY	(Default: No) DDR5 4800Mhz SODIMM x 1, up to 32GB
DISPLAY INTERFACE	HDMI x 2
STORAGE DEVICE	M.2 2280 M-Key x 1 (PCIe Gen 3 [x2]) 2.5" SATA HDD/SSD x 1
ETHERNET	RJ-45 x 2 for 2.5GbE LAN (Intel® I226-LM)
I/O	HDMI x 2 RJ-45 x 2 for 2.5GbE LAN (Intel® Ethernet Controller I226-LM) USB 3.2 Gen 2 (Type-A) x 2 USB 2.0 (Type-A) x 2 DB-9 x 2 for RS-232/422/485 DB-15 x 1 Male for 8-Channel Digital I/O 12V DC Jack Input Power Button with LED x 1 Antenna Opening
EXPANSION	M.2 2280 M-Key x 1 (PCIe [x2]) M.2 2230 E-Key x 1 Full-Size Mini Card x 1 (PCIe + USB) SIM Slot x 1
INDICATOR	Power Button with LED
OS SUPPORT	Windows® 10 IoT Enterprise Windows® 11 Pro Ubuntu 22.04
POWER SUPPLY
POWER REQUIREMENT	Lockable DC Jack x 1 for 12V DC-in
MECHANICAL
MOUNTING	Wallmount
DIMENSIONS (W X H X D)	6.46" x 4.11" x 1.85" (164mm x 104.5mm x 47mm) without bracket 8.74" x 4.11" x 2.13" (222mm x 104.5mm x 54mm) with bracket
GROSS WEIGHT	3.8 lb. (1.73Kg)
NET WEIGHT	2 lb. (0.93Kg)
ENVIRONMENTAL
OPERATING TEMPERATURE	-4°F ~ 140°F (-20°C ~ 60°C), according to IEC68-2 with 0.7 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM)
STORAGE TEMPERATURE	-40°F ~ 176°F (-40°C ~ 80°C)
STORAGE HUMIDITY	5 ~ 95% @ 40°C, non-condensing
ANTI-VIBRATION	With SSD: Random, 3 Grms, 5~500Hz
ANTI-SHOCK	With SSD: 50 G, IEC 60068-2-27, half sine, 11 ms duration
CERTIFICATION	CE/FCC Class A

BOXER-6406U-ADN-A3-1010

SYSTEM
CPU	Intel Atom® x7211E
CHIPSET	Intel® SoC
SYSTEM MEMORY	(Default: No) DDR5 4800Mhz SODIMM x 1, up to 32GB
DISPLAY INTERFACE	HDMI x 2
STORAGE DEVICE	M.2 2280 M-Key x 1 (PCIe Gen 3 [x2]) 2.5" SATA HDD/SSD x 1
ETHERNET	RJ-45 x 2 for 2.5GbE LAN (Intel® I226-LM)
I/O	HDMI x 2 RJ-45 x 2 for 2.5GbE LAN (Intel® Ethernet Controller I226-LM) USB 3.2 Gen 2 (Type-A) x 2 USB 2.0 (Type-A) x 2 DB-9 x 2 for RS-232/422/485 DB-15 x 1 Male for 8-Channel Digital I/O 12V DC Jack Input Power Button with LED x 1 Antenna Opening
EXPANSION	M.2 2280 M-Key x 1 (PCIe [x2]) M.2 2230 E-Key x 1 Full-Size Mini Card x 1 (PCIe + USB) SIM Slot x 1
INDICATOR	Power Button with LED
OS SUPPORT	Windows® 10 IoT Enterprise Windows® 11 Pro Ubuntu 22.04
POWER SUPPLY
POWER REQUIREMENT	Lockable DC Jack x 1 for 12V DC-in
MECHANICAL
MOUNTING	Wallmount
DIMENSIONS (W X H X D)	6.46" x 4.11" x 1.85" (164mm x 104.5mm x 47mm) without bracket 8.74" x 4.11" x 2.13" (222mm x 104.5mm x 54mm) with bracket
GROSS WEIGHT	3.8 lb. (1.73Kg)
NET WEIGHT	2 lb. (0.93Kg)
ENVIRONMENTAL
OPERATING TEMPERATURE	-4°F ~ 140°F (-20°C ~ 60°C), according to IEC68-2 with 0.7 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM)
STORAGE TEMPERATURE	-40°F ~ 176°F (-40°C ~ 80°C)
STORAGE HUMIDITY	5 ~ 95% @ 40°C, non-condensing
ANTI-VIBRATION	With SSD: Random, 3 Grms, 5~500Hz
ANTI-SHOCK	With SSD: 50 G, IEC 60068-2-27, half sine, 11 ms duration
CERTIFICATION	CE/FCC Class A

Packing List

BOXER-6406U-ADN x 1
Wallmount Bracket x 2
Screw Package x 1
60W 12V Power Adapter x 1

Optional Accessories
Item	DESCRIPTION
Power Cord	Power cord varies from countries and needs to be purchased separately. Please click below link if you'd like to add the power cord to your order as well. - US/ Taiwan Type - Europe Type - Japan Type
