The MXM-ACMA introduces the MXM 3.1 Type A GPU module form factor to the AAEON lineup, offering potent, efficient graphics acceleration powered by Intel® Arc™ A-Series graphics. Equipped with 4GB of GDDR6 memory, ray tracing, and Intel® Deep Link Technologies, the MXM-ACMA expedites data handling and optimizes rendering capabilities for a variety of embedded solutions, such as digital signage, gaming, edge AI, and healthcare imaging.
A Compute Boost for Heavy AI Workloads
With a choice of Intel® Arc™ A370M or Intel® Arc™ A350M GPUs, the MXM-ACMA can harness up to 128 Intel® Xe Matrix Extension (Intel® XMX) engines across up to eight Xe-cores to substantially boost compute power for AI workloads. Meanwhile, its ray tracing technology accelerates the training and inference processes of machine learning models.
More Display Option
Offering quadruple display outputs in the form of either DP++ 1.4 or HDMI 2.1 interfaces, the MXM-ACMA offers a greater variety of visual setup options. Be it for multi-screen digital signage installations or powering interactive gaming environments, the MXM-ACMA guarantees seamless connectivity and stunning visuals.
Designed for Longevity
Suited to embedded deployments in digital signage, casino gaming, and edge AI, the MXM-ACMA is built to last, as illustrated by both its industrial temperature range and broad OS compatibility. The module also supports a variety of open-source, cross-platform development tools including OpenCL™, OpenGL®, OpenVINO™, and DirectX 12 Ultimate, for limitless development potential.
SYSTEM | |
Form Factor | Standard MXM 3.1 Type A form factor |
GPU | Intel® Arc™ A370M GPU (8 Xe-cores, TGP 35W) |
Memory | 4GB GDDR6, 64-bit , Bandwith 112GB/s |
Display Interface | DP++ 1.4 x 4 or HDMI 2.1 x 4 |
Dimension | 3.2" x 2.7" (82mm x 70mm) |
Power Consumption | Intel® Arc™ A370M GPU, TGP 35W |
Operation Temperature | 32°F ~ 140°F (0°C ~ 60°C) in 0.5m/sec airflow |
Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
OS Support | Windows 10 (64bit) / Windows 11 Ubuntu 22.04 LTS |
Others | OpenCL™ 4.6/OpenGL® 3.0/oneAPI/DirectX 12 Ultimate/Ray Tracing Support |
SYSTEM | |
Form Factor | Standard MXM 3.1 Type A form factor |
GPU | Intel® Arc™ A350M GPU (6 Xe-cores, TGP 25W) |
Memory | 4GB GDDR6, 64-bit , Bandwith 112GB/s |
Display Interface | DP++ 1.4 x 4 or HDMI 2.1 x 4 |
Dimension | 3.2" x 2.7" (82mm x 70mm) |
Power Consumption | Intel® Arc™ A350M GPU, TGP 25W |
Operation Temperature | 32°F ~ 140°F (0°C ~ 60°C) in 0.5m/sec airflow |
Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
OS Support | Windows 10 (64bit) / Windows 11 Ubuntu 22.04 LTS |
Others | OpenCL™ 4.6/OpenGL® 3.0/oneAPI/DirectX 12 Ultimate/Ray Tracing Support |
