ATX-Q670A
ATX with 12th/13th/14th Generation Intel® Core™ and Series 2 LGA1700 Socket Processors, TDP Max. 125W, DDR5 DRAM, Multiple Display Ports
As low as
US$323.00
Availability:
In stock
Inventory: please select an item
SKU
ATX-Q670A
With this innovation, the ATX-Q670A can provide customers with an unprecedented 50% increase in bandwidth and also a decrease in power consumption compared to prior generations. Particularly suited to IoT applications, the ATX-Q670A also combines the greatest maximum SATA performance with the very fastest SSD to give customer applications access to higher I/O speeds.
The ATX-Q670A is not just faster, but also far more expansive and accommodating to higher-performance modules, offering two PCIe x16 slots alongside both a PCIe x4 and PCIe x1 slot, in addition to a further three PCI slots. Such specifications, alongside the ATX-Q670A's dual graphic card support mean that it can facilitate everything from video capture to AI calculation for vision-based applications, with four independent 4K@60Hz resolution display capabilities to complete the package.
For additional protection, given the ATX-Q670A's capacity to transfer higher volumes of data, it is equipped with a bootable USB feature to prevent bootable programs from accessing the system via a USB device.
ATX-Q670A-A10-3L-226
| SYSTEM | |
| PROCESSOR | 12th/13th/14th Generation Intel® Core™ (formerly Alder Lake/Raptor Lake) and Series 2 (formerly Bartlett Lake) LGA1700 Socket Processors, TDP Max 125W |
| CHIPSET | Intel® Q670E Chipset |
| MEMORY | DDR5 4000MHz DIMM x 4, up to 192GB Non-ECC, Unbuffered Memory, Dual-Channel Memory Architecture |
| I/O CHIPSET | NCT6126D |
| ETHERNET | Intel® PHY I219-LM Giga LAN x 1 (supports Intel® AMT 12.0) Intel® I210-AT Giga LAN x 1 Intel® I226-LM Giga LAN x 1 RJ-45 x 3, LAN 3 with USB 3.2 Gen 2 x 1 |
| AUDIO | Realtek ALC897 6-Channel High Definition Audio CODEC |
| TPM | TPM 2.0 onboard |
| EXPANSION SLOT | PCIe Gen 5 [x16] x 1 (16 Lanes) PCIe Gen 3 [x1] x 1 (1 Lane, Open Slot) PCIe Gen 4 [x4] x 1 (4 Lanes, Open Slot) PCIe Gen 4 [x16] x 1 (4 lanes) PCI Slot x 3 M.2 3042/3052 B-Key x 1 (PCIe 3.0 [x1]/USB 3.2 Gen 1) Mini PCIe Slot x 1 (PCIe 3.0/USB 2.0) Micro SIM Card Slot x 1 (M.2 B-Key or Mini PCIe Slot) |
| BIOS | 256Mbit Flash ROM, AMI BIOS |
| H/W MONITOR | Temperature Monitor on CPU/Chassis, Voltage Monitor on Vcore/5V/3.3V/12V, Fan Monitor on CPU/Chassis |
| WATCHDOG TIMER | 1~255 step by software program |
| SMART FAN CONTROL | CPU Fan x 1/ Chassis Fan x 3 |
| WAKE ON LAN/ PXE | Yes (WOL / PXE) |
| POWER STATE | S3, S4, S5 |
| GRAPHICS | |
| GRAPHICS CHIPSET | Intel® Graphics Media Accelerator |
| GRAPHICS MULTI DISPLAY | HDMI+HDMI+DP+DP, HDMI+HDMI+DP+VGA, HDMI+VGA+DP+DP |
| VGA | Up to 1920 x 1200 @60Hz (via IT6516B) |
| HDMI | HDMI 2.0, up to 4096 x 2160 @60/30Hz, with Digital Audio |
| DISPLAY PORT | DP 1.4, up to 4096 x 2160 @24Hz or 3840 x 2160 @60 Hz, with Digital Audio |
| ENVIRONMENTAL & POWER & ME | |
| BATTERY | Lithium battery |
| POWER REQUIREMENT | 24-pin ATX Connector x 1, 8-pin ATX 12V Power Connector x 1 |
| OPERATING TEMPERATURE | 32°F ~ 140°F(0 ~ 60°C) (Operational humidity: 60°C @ 90% RH Non-Condensing) |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| CERTIFICATION | CE & FCC Class A |
| FORM FACTOR | ATX Form Factor, 12" x 9.6" (305mm x 244mm) |
| WEIGHT | 1.76 lb (0.8 Kg) |
| MTBF (HOURS) | 281760 |
| REAR PANEL I/O PORTS | |
| USB | USB 3.2 Gen 2 x 3 (10Gbps, if with LAN 3 I226-LM) USB 3.2 Gen 1 x 2 (5Gbps) USB Type C x 1 (5Gbps, 5V, 1.5A, Optional) (All ports are bootable, can be deactivated per BIOS function; USB Power switchable feature) |
| DISPLAY I/O | HDMI 2.0 x 2, DP 1.4 x 2 |
| AUDIO I/O | Audio Jack x 3, Line-in, Mic-in, Line-out |
| LAN I/O | RJ-45 LAN x 3 |
| Serial Port | DB-9 COM x 1 (supports RS-232/422/485, 5V/12V/RI) |
| INTERNAL I/O CONNECTORS | |
| STORAGE | SATA III x 8, supports RAID 0/1/5/10 M.2 2280 M-Key x 1 (PCIe Gen 4.0, 4 Lanes) M.2 2242/80 M-Key x 1 (PCIe Gen 3.0 1 Lane) |
| USB | USB 3.0 Box Header x 1 (2x5P, p=2.54mm), supports USB 3.2 Gen 1 x 2 (USB Power switchable feature) USB 2.0 Header x 1 (2x5P, p=2.54mm) supports USB 2.0 x 2 (USB Power switchable feature) USB 2.0 x 1 (Vertical Type-A) |
| Display I/O | VGA Header x 1 |
| Audio I/O | Speaker header(Line-out), AAFP x 1 |
| Serial Port | RS-232 headers x 5 |
| DIO | 8-bit Digital I/O Interface x 1 (In/Out Programmable) |
| FAN | 4-pin CPU Fan Connector x 1 (PWM Mode) 4-pin Chassis Fan Connector x 3 (PWM Mode) |
| OTHERS | Chassis Intrusion x 1, AT/ATX Mode Select Jumper x 1, Front Panel Header x 1 Clear CMOS Jumper x 1, Buzzer Onboard x 1, 3-pin ME Lock Header x 1 |
| OS | |
| OS SUPPORT | Windows® 10 64-bit, Windows® 11 64-bit |
ATX-Q670A-A10-2L
| SYSTEM | |
| PROCESSOR | 12th/13th/14th Generation Intel® Core™ (formerly Alder Lake/Raptor Lake) and Series 2 (formerly Bartlett Lake) LGA1700 Socket Processors, TDP Max 125W |
| CHIPSET | Intel® Q670E Chipset |
| MEMORY | DDR5 4000MHz DIMM x 4, up to 192GB Non-ECC, Unbuffered Memory, Dual-Channel Memory Architecture |
| I/O CHIPSET | NCT6126D |
| ETHERNET | Intel® PHY I219-LM Giga LAN x 1 (supports Intel® AMT 12.0) Intel® I210-AT Giga LAN x 1 RJ-45 x 2 |
| AUDIO | Realtek ALC897 6-Channel High Definition Audio CODEC |
| TPM | TPM 2.0 onboard |
| EXPANSION SLOT | PCIe Gen 5 [x16] x 1 (16 Lanes) PCIe Gen 3 [x1] x 1 (1 Lane, Open Slot) PCIe Gen 4 [x4] x 1 (4 Lanes, Open Slot) PCIe Gen 4 [x16] x 1 (4 lanes) PCI Slot x 3 M.2 3042/3052 B-Key x 1 (PCIe 3.0 [x1]/USB 3.2 Gen 1) Mini PCIe Slot x 1 (PCIe 3.0/USB 2.0) Micro SIM Card Slot x 1 (M.2 B-Key or Mini PCIe Slot) |
| BIOS | 256Mbit Flash ROM, AMI BIOS |
| H/W MONITOR | Temperature Monitor on CPU/Chassis, Voltage Monitor on Vcore/5V/3.3V/12V, Fan Monitor on CPU/Chassis |
| WATCHDOG TIMER | 1~255 step by software program |
| SMART FAN CONTROL | CPU Fan x 1/ Chassis Fan x 3 |
| WAKE ON LAN/ PXE | Yes (WOL / PXE) |
| POWER STATE | S3, S4, S5 |
| GRAPHICS | |
| GRAPHICS CHIPSET | Intel® Graphics Media Accelerator |
| GRAPHICS MULTI DISPLAY | HDMI+HDMI+DP+DP, HDMI+HDMI+DP+VGA, HDMI+VGA+DP+DP |
| VGA | Up to 1920 x 1200 @60Hz (via IT6516B) |
| HDMI | HDMI 2.0, up to 4096 x 2160 @60/30Hz, with Digital Audio |
| DISPLAY PORT | DP 1.4, up to 4096 x 2160 @24Hz or 3840 x 2160 @60 Hz, with Digital Audio |
| ENVIRONMENTAL & POWER & ME | |
| BATTERY | Lithium battery |
| POWER REQUIREMENT | 24-pin ATX Connector x 1, 8-pin ATX 12V Power Connector x 1 |
| OPERATING TEMPERATURE | 32°F ~ 140°F(0 ~ 60°C) (Operational humidity: 60°C @ 90% RH Non-Condensing) |
| STORAGE TEMPERATURE | -40°F ~ 185°F (-40°C ~ 85°C) |
| CERTIFICATION | CE & FCC Class A |
| FORM FACTOR | ATX Form Factor, 12" x 9.6" (305mm x 244mm) |
| WEIGHT | 1.76 lb (0.8 Kg) |
| MTBF (HOURS) | 281760 |
| REAR PANEL I/O PORTS | |
| USB | USB 3.2 Gen 2 x 2 (10Gbps) USB 3.2 Gen 1 x 2 (5Gbps) USB Type C x 1 (5Gbps, 5V, 1.5A, Optional) (All ports are bootable, can be deactivated per BIOS function; USB Power switchable feature) |
| DISPLAY I/O | HDMI 2.0 x 2, DP 1.4 x 2 |
| AUDIO I/O | Audio Jack x 3, Line-in, Mic-in, Line-out |
| LAN I/O | RJ-45 LAN x 2 |
| Serial Port | DB-9 COM x 1 (supports RS-232/422/485, 5V/12V/RI) |
| INTERNAL I/O CONNECTORS | |
| STORAGE | SATA III x 8, supports RAID 0/1/5/10 M.2 2280 M-Key x 1 (PCIe Gen 4.0, 4 Lanes) M.2 2242/80 M-Key x 1 (PCIe Gen 3.0 1 Lane) |
| USB | USB 3.0 Box Header x 1 (2x5P, p=2.54mm), supports USB 3.2 Gen 1 x 2 (USB Power switchable feature) USB 2.0 Header x 1 (2x5P, p=2.54mm) supports USB 2.0 x 2 (USB Power switchable feature) USB 2.0 x 1 (Vertical Type-A) |
| Display I/O | VGA Header x 1 |
| Audio I/O | Speaker header(Line-out), AAFP x 1 |
| Serial Port | RS-232 headers x 5 |
| DIO | 8-bit Digital I/O Interface x 1 (In/Out Programmable) |
| FAN | 4-pin CPU Fan Connector x 1 (PWM Mode) 4-pin Chassis Fan Connector x 3 (PWM Mode) |
| OTHERS | Chassis Intrusion x 1, AT/ATX Mode Select Jumper x 1, Front Panel Header x 1 Clear CMOS Jumper x 1, Buzzer Onboard x 1, 3-pin ME Lock Header x 1 |
| OS | |
| OS SUPPORT | Windows® 10 64-bit, Windows® 11 64-bit |
- 14001-0063010: SATA 6G Cable (7P, 180; 90, 500mm 2 in1)
- 14019-00060700: VGA Cable (320mm, 2X8P, w/bracket)
- I/O Shield
- ATX-Q670A
| Optional Accessories | |
| Item | DESCRIPTION |
|
1U CPU Cooler (up to 125W) |
Please click HERE if you'd like to add it to your order. |
|
2U CPU Cooler (up to 125W) |
Please click HERE if you'd like to add it to your order. |
|
2U CPU Cooler (up to 95W) |
Please click HERE if you'd like to add it to your order. |
|
USB 2.0 cable (w/bracket) |
Please click HERE if you'd like to add it to your order. |
|
USB 2.0 cable (w/o bracket) |
Please click HERE if you'd like to add it to your order. |
|
USB 3.2 cable |
Please click HERE if you'd like to add it to your order. |
